300 W CW over 2400-2500 MHz, 32 V RF Power LDMOS Transistor
- このページには、製造中止（生産終了）となった製品の情報が記載されています。本ページに記載されている仕様および情報は、過去の参考情報です。
The MRF24300N 300 W CW transistor is designed for industrial, scientific, medical (ISM) applications at 2450 MHz. This device is suitable for use in CW, pulse and linear applications. This high gain, high efficiency device is targeted to replace industrial magnetrons and will provide longer life and ease of use.
製品詳細
Features
- Characterized with series equivalent large-signal impedance parameters
- Internally matched for ease of use
- Qualified for operation at 32 Vdc
- Integrated ESD protection
- Low thermal resistance
- RoHS Compliant
- Industrial heating:
- Sterilization
- Pasteurization
- Industrial drying
- Moisture-leveling process
- Curing
- Welding
- Heat sealing
- Microwave ablation
- Renal denervation
- Diathermy
RF Performance Tables
Typical Performance
In 2400-2500 MHz reference circuit, VDD = 32 Vdc| Frequency (MHz) |
Signal Type | Pin (W) |
Gps (dB) |
ηD (%) |
Pout (W) |
| 2450 | CW | 15.9 | 13.1 | 60.5 | 320 |
Load Mismatch/Ruggedness
| Frequency (MHz) |
Signal Type | VSWR | Pin (W) |
Test Voltage |
Result |
| 2450 1 | CW | > 5:1 at all Phase Angles | 15.0 (2 dB Overdrive) | 32 | No Device Degradation |
