920-960 MHz, 63 W Avg., 28 V Single W-CDMA RF Power LDMOS Transistor
- このページには、製造中止（生産終了）となった製品の情報が記載されています。本ページに記載されている仕様および情報は、過去の参考情報です。
The MRF8P9210NR3 is designed for CDMA base station applications with frequencies from 920 to 960 MHz. Can be used in Class AB and Class C for all typical cellular base station modulation formats.
製品詳細
RF Performance Table
900 MHz
Typical Doherty Single-Carrier W-CDMA Characterization Performance: VDD = 28 Volts, IDQA = 750 mA, VGSB = 1.2 Vdc, Pout = 63 Watts Avg., IQ Magnitude Clipping, Channel Bandwidth = 3.84 MHz, Input Signal PAR = 7.5 dB @ 0.01% Probability on CCDF.| Frequency | Gps (dB) |
ηD (%) |
Output PAR (dB) |
ACPR (dBc) |
| 920 MHz | 16.5 | 46.2 | 6.2 | –31.3 |
| 940 MHz | 16.9 | 47.7 | 6.0 | –32.6 |
| 960 MHz | 16.7 | 47.4 | 5.8 | –34.4 |
- Capable of Handling 10:1 VSWR, @ 32 Vdc, 960 MHz, 253 Watts CW Output Power (3 dB Input Overdrive from Rated Pout), Designed for Enhanced Ruggedness
- Typical Pout @ 3 dB Compression Point ≃ 290 Watts
