PowerQUICC® Processor with CPM (1 SCC, 1 SMC), 10/100 Ethernet
- このページには、製造中止（生産終了）となった製品の情報が記載されています。本ページに記載されている仕様および情報は、過去の参考情報です。
The MPC857DSL Integrated Communications Controller is a versatile one-chip integrated microprocesor and peripheral combination that can be used in a variety of controller applications. It particularly excels in CPE applications including DSL modems, IADs, and residential gateways.
The MPC857DSL is a Power Architecture-based derivative of NXP® Semiconductors's Quad Integrated Communications Controller (PowerQUICC). The embedded CPU on the MPC857DSL is the MPC8xx core, a 32-bit microprocessor built on Power Architecture technology, incorporating memory management units (MMUs) and instruction and data caches. The memory controller supports many memory types, including SDRAM. The CPM (Communications Processing Module) is optimized for CPE applications supporting simultaneous operation of Fast Ethernet (MII) and parallel ATM (UTOPIA), UTOPIA II Multi-PHY (up to 4 addresses), and many more features.
