High Voltage Wireless Charging Receiver

WPR1500-HV

画像にカーソルを合わせると拡大表示されます。

The high voltage wireless charging receiver reference platform with BUCK-BOOST architecture uses our MWPR1516 receiver controller IC to manage and perform all control functions necessary to implement a wireless charging receiver solution. The WPR1500-HV complies with the Wireless Power Consortium's latest Qi v1.3 specification including authentication and can be charged by any Qi-certified transmitter devices. High voltage management helps enable 30-watt power delivery and supports customized fast charging protocols.

Features

  • Compliant with the EPP WPC Qi V1.3x specification, compatible with V1.2.4
  • Input voltage (3.5 V – 20 V AC peak) from the transmitter through the receiver coil
  • Output voltage range can be set from 3.5 V to 20 V
  • Default output power 15 W(12 V@1.25 A), can be extended up to 30 W(20 V@1.5 A)
  • Hardware protection of rectifier voltage, output voltage and output current
  • Software based solution to provide maximum design freedom and product differentiation
  • Enhanced EMC performance
  • Power transfer efficiency exceeds 80%

購入オプション

WPR1500-HV-Image

クリックして展開

  • WPR1500-HV
    アクティブ

  • High Voltage Wireless Charging Receiver.

  • $208.00 USD
  • の数量に対して 1
    • 在庫: 保留中の在庫
カートに入れる
代理店からの注文
