Ultra-Low-Power, 1.8 V, 1 Deg. C Accuracy, Digital Temperature Sensor with I2C-Bus Interface
- このページには、製造中止（生産終了）となった製品の情報が記載されています。本ページに記載されている仕様および情報は、過去の参考情報です。
The PCT2202 is an I²C bus, serial output temperature sensor available in a tiny WLCSP6 package. Requiring no external components, the PCT2202 is capable of reading temperatures at 12-bit resolution or 0.0625 °C with an accuracy of ±0.5 °C from 0 °C to 85 °C.
The PCT2202 features SMBus and I²C bus interface compatibility including HSM (High-Speed Mode: 3.4 MHz) and allows up to four devices on one bus. It also features an SMB alert function.
The PCT2202 is ideal for extended temperature measurement in a variety of communication, computer, consumer, environmental, industrial, and instrumentation applications. The device is specified for operation over a temperature range of ‑40 °C to +125 °C and a voltage range of 1.65 V to 1.95 V.
製品詳細
Features
Key Features
- Tiny WLCSP6 package
- Accuracy: 0.5 °C from 0 °C to +85 °C
- Supply range: 1.8 V ± 0.15 V
- Resolution: 12 bits
- Two-wire I²C bus serial interface including HS Mode 3.4 MHz
- Firmware identical to TMP102
- ESD protection exceeds 2000 V HBM per JESD22-A114 and 1000 V CDM per JESD22-C101
- Latch-up testing is done to JEDEC Standard JESD78 which exceeds 100 mA
Low Quiescent Current
- 30 μA Active
- 1 μA Shut-down
