Embedded Component: NXPCMT
The carrier modulator transmitter (CMT) module provides a means to generate the protocol timing and carrier signals for a variety of encoding schemes. The CMT does not include dedicated hardware configurations for specific protocols but is intended to be sufficiently programmable in its function to handle the timing requirements of most protocols with minimal CPU intervention. The CMT consist of a carrier generator, modulator and transmitter which drives the infrared output pin. Modulation cycle consist of two parts: Mark and space.
ソフトウェア詳細
Features
- Four Operation modes: Time, Baseband, FSK, Direct SW control of output pin
- Extended space operation
- Interrupt event on end of modulation cycle
- Enable
- Disable
- EnableEvent
- DisableEvent
- SwapCarrierFreq
- SetSpaceWidthMode
- SetMarkWidthMode
- SetExtendedSpace
- SetValue
- ClrValue
対応製品
- MCF51JE: Flexis™ 32ビットColdFire®。V1マイクロコントローラ
- MCF51MM: Flexis 32ビットColdFire® V1 MCU
- S08JE: 8-bit Flexis USB JE MCUs
- S08MM: 8-bit Flexis USB MM128/64/32 MCUs
- S08R: 8-bit S08RC, S08RD, S08RE and S08RG MCUs
- VF3xx: Arm® Cortex®-A5-Based Microprocessors with 1.5MB SRAM, LCD, Security, 2x Ethernet and L2 Switch
- VF5xx: Arm® Cortex®-A5-Based Microprocessors with 1.5MB SRAM, LCD, Security, 2x Ethernet and L2 Switch
- VF6xx: Arm® Cortex®-A5 + Cortex-M4 MPUs, 1.5 MB SRAM, LCD, Security, Ethernet, L2 Switch
購入オプション
This Embedded Component can be purchased for $125 and added to the Special and Standard Editions of CodeWarrior. Please note, this Embedded Component is included in the CodeWarrior Development Suite - Professional Edition.
