NPN Wideband Silicon RF Transistor

BFU530
アクティブ

NPN silicon RF transistor for high speed, low noise applications in a plastic, 4-pin dual-emitter SOT143B package.

The BFU530 is part of the BFU5 family of transistors, suitable for small signal to medium power applications up to 2 GHz.

製品画像を見る

製品詳細

Features

  • Low noise, high breakdown RF transistor
  • AEC-Q101 qualified
  • Minimum noise figure (NFmin) = 0.7 dB at 900 MHz
  • Maximum stable gain 21.5 dB at 900 MHz
  • 11 GHz fT silicon technology

Target Applications

  • Applications requiring high supply voltages and high breakdown voltages
  • Broadband amplifiers up to 2 GHz
  • Low noise amplifiers for ISM applications
  • ISM band oscillators

購入/パラメータ

1 結果

マッチしていない 0 NRND

パーツ

説明を表示

注文

コンピュータ支援設計 モデル

Generation

fT [typ] (MHz)

VCEO [max] (V)

Ptot [max] (mW)

Polarity

@f (MHz)

@VCE (V)

@IC (mA)

NF (dB)

状況

BFU530
データ・シート

5th

11000

12

450

NPN

900

8

1

0.7

アクティブ
