NFC Reader Library: Software Support for NFC Frontend Solutions

NFC-READER-LIBRARY

画像にカーソルを合わせると拡大表示されます。

Feature complete software support library for NFC Frontend ICs. Designed to give developers a faster and simpler way to deliver NFC-enabled products. This multi-layer library, written in C, makes it easy to create NFC based applications. Special features, including interrupt-based event handling, Free RTOS support and MISRA-C compliancy, are provided along with the NFC Reader Library. The software is designed in a way to be easily portable to many different microcontrollers.

ソフトウェア詳細

Features

  • All NXP® NFC frontend ICs
  • Full feature set according to NFC Forum
  • Synchronous API
  • Modular, multi-layer design
  • Interrupt-based event handling
  • Supports RTOS and non RTOS based architecture
  • Supports multiple development environments
  • Certification test applications for EMVCo L1, NFC Forum, ISO/IEC 10373-6 PICC/PCD
  • Same software stack for PN5190, PN5180, CLRC663, PN74 family and PN76 family
  • Easy switching between reader IC
  • Built-in MCU support: LPC1769, Kinetis K82
  • Host interfaces: I²C, SPI, UART, I3C, or custom (availability of interfaces dependent on NFC Reader IC)
  • Wide range of sample applications
  • Support for FRDM-K82F Platform
  • Support for Linux on Raspberry Pi Model 3 Platform
  • Simplified API for EMVCo and ISO Profile
  • Configuration for variable preamble reception related to FeliCa
  • Improvements on platform porting layer

Since Android 12, P2P functionality is not included by default in the main package. Moreover this functionality has never been supported by iOS devices. P2P is slowly removed from the market. At NFC Forum, the P2P functionality is not available for the Reader device class since CR13 and NXP does not expect any significant changes on the defined functionality. For this reason NXP plans to stop the maintenance of the P2P functionality in the NFC Reader library from 2024 onwards. The existing library versions which include the P2P support will be still available for download

ダウンロード

クイック・リファレンス ソフトウェア・タイプ.
フィルタ

1 ダウンロード

  • ライブラリ

    NFC Reader Library - Software Support for NFC Frontend Solutions

    FLEXERA改訂 07.11.00Dec 5, 20241 KBNFC-LIBRARY-SOFTWARE
    ダウンロード

注: より快適にご利用いただくために、ソフトウェアのダウンロードはデスクトップで行うことを推奨します。

Y true 0 SSPNFC-READER-LIBRARYja 9 アプリケーション・ノート Application Note t789 5 ユーザ・ガイド User Guide t792 3 リリース・ノート Release Note t933 1 ja ja ja アプリケーション・ノート Application Note 5 1 1.8 English This application note describes how to install NXP’s NFC Reader Library on a GNU/Linux system. 1459972315005712302126 SSP 15.7 MB None None documents None 1459972315005712302126 /docs/en/application-note/AN11802.pdf 15736577 /docs/en/application-note/AN11802.pdf AN11802 documents N N 2016-10-08 NFC Reader Library for Linux installation guidelines /docs/en/application-note/AN11802.pdf /docs/en/application-note/AN11802.pdf Application Note N 645036621402383989 2023-07-24 pdf N en Dec 21, 2022 645036621402383989 Application Note Y N NFC Reader Library for Linux installation guidelines PDF 2 2.5 English 1442088713603711487495 SSP 2.9 MB None None documents None 1442088713603711487495 /docs/en/application-note/AN11308.pdf 2921810 /docs/en/application-note/AN11308.pdf AN11308 documents N N 2016-10-08 Quick Start Up Guide PNEV512B Board /docs/en/application-note/AN11308.pdf /docs/en/application-note/AN11308.pdf Application Note N 645036621402383989 2022-12-07 pdf N en Sep 26, 2018 645036621402383989 Application Note Y N Quick Start Up Guide PNEV512B Board PDF 3 1.3 English NFC Reader Library for KDS Installation guidelines 1481120855111708266745 SSP 1.1 MB None None documents None 1481120855111708266745 /docs/en/application-note/AN11908.pdf 1089635 /docs/en/application-note/AN11908.pdf AN11908 documents N N 2016-12-07 NFC Reader Library for FRDM - K82F Board Installation guidelines /docs/en/application-note/AN11908.pdf /docs/en/application-note/AN11908.pdf Application Note N 645036621402383989 2022-12-07 pdf N en Apr 18, 2018 645036621402383989 Application Note Y N NFC Reader Library for FRDM - K82F Board Installation guidelines 4 0 English The NFC Reader Library is a feature complete software support library for NXP's NFC frontend ICs. It is designed to give developers a faster and simpler way to deliver NFC-enabled products. 1519296685496734500552 SSP 450.9 KB None None documents None 1519296685496734500552 /docs/en/nxp/application-notes/AN12129.pdf 450943 /docs/en/nxp/application-notes/AN12129.pdf AN12129 documents N N 2018-02-22 NFC Read Library for i.MX7Dual Sabre /docs/en/nxp/application-notes/AN12129.pdf /docs/en/nxp/application-notes/AN12129.pdf Application Note N 645036621402383989 2023-06-18 pdf N en Feb 21, 2018 645036621402383989 Application Note Y N NFC Read Library for i.MX7Dual Sabre 5 2.0 English 1442088223817722899938 SSP 678.2 KB None None documents None 1442088223817722899938 /docs/en/application-note/AN11145.pdf 678239 /docs/en/application-note/AN11145.pdf AN11145 documents N N 2016-10-08 CLRC663, MFRC631, MFRC 630, SLRC610 Low Power CardDetection /docs/en/application-note/AN11145.pdf /docs/en/application-note/AN11145.pdf Application Note N 645036621402383989 2022-12-07 pdf N en May 4, 2015 645036621402383989 Application Note Y N CLRC663, MFRC631, MFRC 630, SLRC610 Low Power CardDetection PDF ユーザ・ガイド User Guide 3 6 1.7 English This user manual is related to the installation procedures of the PN5180 evaluation board, which are related to the installation of the SW sample projects as well as the re-installation of the original LPC firmware to run the NFC Cockpit. It describes the steps to be done to become acquainted with the demo reader especially for SW development. 1448641448624734131055 SSP 1.6 MB None None documents None 1448641448624734131055 /docs/en/user-guide/UM10954.pdf 1607223 /docs/en/user-guide/UM10954.pdf UM10954 documents N N 2016-10-08 PN5180 SW Quick start guide /docs/en/user-guide/UM10954.pdf /docs/en/user-guide/UM10954.pdf User Guide N 132339537837198660 2023-06-19 pdf N en Dec 5, 2022 132339537837198660 User Guide Y N PN5180 SW Quick start guide pdf 7 1.3 Chinese 本文描述了恩智浦公共读卡器库的实施和使用，重点介绍了MIFARE Classic命令和CLRC663本机命令集的实施。 1442125007893714132218zh SSP 619.6 KB Registration without Disclaimer None documents Extended 1442125007893714132218 /secured/assets/documents/zh/user-guide/UM10663.pdf 619577 /secured/assets/documents/zh/user-guide/UM10663.pdf UM10663 documents Y N 2016-10-08 NXP Reader Library User Manual based on CLRC663 and PN512 Blueboard Reader projects /secured/assets/documents/zh/user-guide/UM10663.pdf https://www.nxp.com.cn/webapp/Download?colCode=UM10663&docLang=zh User Guide N 132339537837198660 2022-12-07 zh Aug 5, 2018 132339537837198660 User Guide Y N 恩智浦读卡器库用户手册，以 CLRC663 和 PN512 Blueboard 读卡器 项目为基础 PDF 1.3 English This document describes the implementation and usage of the NXP Reader Library Public with special stress on MIFARE Classic command and CLRC663 native command set implementation. 1442125007893714132218 SSP 619.6 KB Registration without Disclaimer None documents Extended 1442125007893714132218 /secured/assets/documents/en/user-guide/UM10663.pdf 619577 /secured/assets/documents/en/user-guide/UM10663.pdf UM10663 documents Y N 2016-10-08 NXP Reader Library User Manual based on CLRC663 and PN512 Blueboard Reader projects /webapp/Download?colCode=UM10663&lang_cd=ja /secured/assets/documents/en/user-guide/UM10663.pdf User Guide N 132339537837198660 2022-12-07 pdf Y en Aug 5, 2018 132339537837198660 User Guide Y N NXP Reader Library User Manual based on CLRC663 and PN512 Blueboard Reader projects PDF 8 1.2 English This document informs the reader about the architecture functionalities of the NXP Reader Library Peer to Peer with stress on LLCP API layer 1442125913795710574163 SSP 1.8 MB Registration without Disclaimer None documents Extended 1442125913795710574163 /secured/assets/documents/en/user-guide/UM10721.pdf 1775950 /secured/assets/documents/en/user-guide/UM10721.pdf UM10721 documents Y N 2016-10-08 NXP Reader Library Peer to Peer User Manual based on CLRC663 and PN512 Blueboard Reader projects /webapp/Download?colCode=UM10721&lang_cd=ja /secured/assets/documents/en/user-guide/UM10721.pdf User Guide N 132339537837198660 2022-12-07 pdf Y en Aug 5, 2018 132339537837198660 User Guide Y N NXP Reader Library Peer to Peer User Manual based on CLRC663 and PN512 Blueboard Reader projects PDF リリース・ノート Release Note 1 9 2.3 English Release Note for NFC Reader Library version 07.08.00 1481121078109724850027 SSP 215.9 KB None None documents None 1481121078109724850027 /docs/en/release-note/RN00009.pdf 215922 /docs/en/release-note/RN00009.pdf RN00009 documents N N 2016-12-07 NFC Reader Library version 07.09.00 /docs/en/release-note/RN00009.pdf /docs/en/release-note/RN00009.pdf Release Note N 487216834315582133 2023-09-21 pdf N en Sep 3, 2023 487216834315582133 Release Note Y N NFC Reader Library version 07.09.00 false 0 NFC-READER-LIBRARY downloads ja true 1 Y SSP Y Y アプリケーション・ノート 5 /docs/en/application-note/AN11802.pdf 2016-10-08 1459972315005712302126 SSP 1 Dec 21, 2022 Application Note This application note describes how to install NXP’s NFC Reader Library on a GNU/Linux system. PDF None /docs/en/application-note/AN11802.pdf English documents 15736577 None 645036621402383989 2023-07-24 N /docs/en/application-note/AN11802.pdf NFC Reader Library for Linux installation guidelines /docs/en/application-note/AN11802.pdf documents 645036621402383989 Application Note N en None Y pdf 1.8 N N NFC Reader Library for Linux installation guidelines 15.7 MB AN11802 N 1459972315005712302126 /docs/en/application-note/AN11308.pdf 2016-10-08 1442088713603711487495 SSP 2 Sep 26, 2018 Application Note PDF None /docs/en/application-note/AN11308.pdf English documents 2921810 None 645036621402383989 2022-12-07 N /docs/en/application-note/AN11308.pdf Quick Start Up Guide PNEV512B Board /docs/en/application-note/AN11308.pdf documents 645036621402383989 Application Note N en None Y pdf 2.5 N N Quick Start Up Guide PNEV512B Board 2.9 MB AN11308 N 1442088713603711487495 /docs/en/application-note/AN11908.pdf 2016-12-07 1481120855111708266745 SSP 3 Apr 18, 2018 Application Note NFC Reader Library for KDS Installation guidelines None /docs/en/application-note/AN11908.pdf English documents 1089635 None 645036621402383989 2022-12-07 N /docs/en/application-note/AN11908.pdf NFC Reader Library for FRDM - K82F Board Installation guidelines /docs/en/application-note/AN11908.pdf documents 645036621402383989 Application Note N en None Y pdf 1.3 N N NFC Reader Library for FRDM - K82F Board Installation guidelines 1.1 MB AN11908 N 1481120855111708266745 /docs/en/nxp/application-notes/AN12129.pdf 2018-02-22 1519296685496734500552 SSP 4 Feb 21, 2018 Application Note The NFC Reader Library is a feature complete software support library for NXP's NFC frontend ICs. It is designed to give developers a faster and simpler way to deliver NFC-enabled products. None /docs/en/nxp/application-notes/AN12129.pdf English documents 450943 None 645036621402383989 2023-06-18 N /docs/en/nxp/application-notes/AN12129.pdf NFC Read Library for i.MX7Dual Sabre /docs/en/nxp/application-notes/AN12129.pdf documents 645036621402383989 Application Note N en None Y pdf 0 N N NFC Read Library for i.MX7Dual Sabre 450.9 KB AN12129 N 1519296685496734500552 /docs/en/application-note/AN11145.pdf 2016-10-08 1442088223817722899938 SSP 5 May 4, 2015 Application Note PDF None /docs/en/application-note/AN11145.pdf English documents 678239 None 645036621402383989 2022-12-07 N /docs/en/application-note/AN11145.pdf CLRC663, MFRC631, MFRC 630, SLRC610 Low Power CardDetection /docs/en/application-note/AN11145.pdf documents 645036621402383989 Application Note N en None Y pdf 2.0 N N CLRC663, MFRC631, MFRC 630, SLRC610 Low Power CardDetection 678.2 KB AN11145 N 1442088223817722899938 ユーザ・ガイド 3 /docs/en/user-guide/UM10954.pdf 2016-10-08 1448641448624734131055 SSP 6 Dec 5, 2022 User Guide This user manual is related to the installation procedures of the PN5180 evaluation board, which are related to the installation of the SW sample projects as well as the re-installation of the original LPC firmware to run the NFC Cockpit. It describes the steps to be done to become acquainted with the demo reader especially for SW development. pdf None /docs/en/user-guide/UM10954.pdf English documents 1607223 None 132339537837198660 2023-06-19 N /docs/en/user-guide/UM10954.pdf PN5180 SW Quick start guide /docs/en/user-guide/UM10954.pdf documents 132339537837198660 User Guide N en None Y pdf 1.7 N N PN5180 SW Quick start guide 1.6 MB UM10954 N 1448641448624734131055 /secured/assets/documents/en/user-guide/UM10663.pdf 2016-10-08 1442125007893714132218 SSP 7 Aug 5, 2018 User Guide This document describes the implementation and usage of the NXP Reader Library Public with special stress on MIFARE Classic command and CLRC663 native command set implementation. PDF Registration without Disclaimer /secured/assets/documents/en/user-guide/UM10663.pdf English documents 619577 None 132339537837198660 2022-12-07 Y /webapp/Download?colCode=UM10663&lang_cd=ja NXP Reader Library User Manual based on CLRC663 and PN512 Blueboard Reader projects /secured/assets/documents/en/user-guide/UM10663.pdf documents 132339537837198660 User Guide N en Extended Y pdf 1.3 Y N NXP Reader Library User Manual based on CLRC663 and PN512 Blueboard Reader projects 619.6 KB UM10663 N 1442125007893714132218 /secured/assets/documents/en/user-guide/UM10721.pdf 2016-10-08 1442125913795710574163 SSP 8 Aug 5, 2018 User Guide This document informs the reader about the architecture functionalities of the NXP Reader Library Peer to Peer with stress on LLCP API layer PDF Registration without Disclaimer /secured/assets/documents/en/user-guide/UM10721.pdf English documents 1775950 None 132339537837198660 2022-12-07 Y /webapp/Download?colCode=UM10721&lang_cd=ja NXP Reader Library Peer to Peer User Manual based on CLRC663 and PN512 Blueboard Reader projects /secured/assets/documents/en/user-guide/UM10721.pdf documents 132339537837198660 User Guide N en Extended Y pdf 1.2 Y N NXP Reader Library Peer to Peer User Manual based on CLRC663 and PN512 Blueboard Reader projects 1.8 MB UM10721 N 1442125913795710574163 リリース・ノート 1 /docs/en/release-note/RN00009.pdf 2016-12-07 1481121078109724850027 SSP 9 Sep 3, 2023 Release Note Release Note for NFC Reader Library version 07.08.00 None /docs/en/release-note/RN00009.pdf English documents 215922 None 487216834315582133 2023-09-21 N /docs/en/release-note/RN00009.pdf NFC Reader Library version 07.09.00 /docs/en/release-note/RN00009.pdf documents 487216834315582133 Release Note N en None Y pdf 2.3 N N NFC Reader Library version 07.09.00 215.9 KB RN00009 N 1481121078109724850027 true Y Softwares

ドキュメント

クイック・リファレンス ドキュメンテーションの種類.

フィルタ

9 ドキュメント

コンパクトリスト

アプリケーション・ノート (5)
ユーザ・ガイド (3)
リリース・ノート (1)
