Real-Time Clock/Calendar
The PCA8565A is a CMOS Real-Time Clock (RTC) and calendar optimized for low power consumption. A programmable clock output, interrupt output, and voltage-low detector are also provided. All addresses and data are transferred serially via a two-line bidirectional I²C-bus. Maximum bus speed is 400 kbit/s. The built-in word address register is incremented automatically after each written or read data byte.
製品詳細
Features
Key Features
- AEC-Q100 compliant for automotive applications
- Provides year, month, day, weekday, hours, minutes, and seconds based on 32.768 kHz quartz crystal
- Clock operating voltage: 1.8 V to 5.5 V
- Extended operating temperature range: -40 °C to +125 °C
- Low backup current: typical 0.65 μA at VDD = 3.0 V and Tamb = 25 °C
- 400 kHz two-line I²C-bus interface (at VDD = 1.8 V to 5.5 V)
- Programmable clock output for peripheral devices (32.768 kHz, 1.024 kHz, 32 Hz, and 1 Hz)
- Alarm and timer functions
- Two integrated oscillator capacitors
- Internal Power-On Reset (POR)
- I²C-bus target address: read A3h; write A2h
- Open-drain interrupt pin
購入/パラメータ
1 結果
マッチしていない 1 NRND
パーツ | 注文 | コンピュータ支援設計 モデル | 状況 | RTC Type | Accuracy (Typ) (+/- ppm) | 電源電圧 [最小 - 最大] (V) | Low Supply Current (μA) | 通信プロトコル | Capacitive Load (μF) | Battery Back Up | Watchdog timer | Programmable alarm | Countdown Timer | Tamper Input | Interrupt Output | Integrated Temperature Compensation | Operating Temperature (Min-Max) (℃) | AEC-Q100 compliant | パッケージタイプ | パッケージ端子数 | Package Pitch (mm) | Package Area (mm2) | Package Dimensions (LxWxZ (mm)) | 標準価格 | VDD (clock) | VDD (interface) | Ambient Operating Temperature (Min to Max) (℃) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
アクティブ | IC | 20 to 50 at 25°C | 1 to 5.5, 1.8 to 5.5 | 0.65 | I²C | 10 | No | Y | Y | Y | 0 | 1 | N | -40 to 125 | Y | TSSOP8 | 8 | 0.65 | 15.81 | 3 x 3 x 1.1 | 1K @ US$0.76 | 1 to 5.5 | 1.8 to 5.5 | -40 to 125 |
