BlueBox 3.0 Automotive High-Performance Compute (AHPC) Development Platform
- The BlueBox development platform is not available for new projects.
The NXP BlueBox development platform provides the necessary performance and functional safety features to build both zonal architectures and high-performance computing systems. BlueBox enables the analyzation of driving environments, including risk factors, for software-defined vehicles and directs the behavior of self-driving cars.
BlueBox 3 family is the latest addition to the series, which incorporates the the Layerscape® LX2160A embedded processor. The LX2160A is pair with the ASIL D ready S32G2 vehicle network processor for automotive service-oriented gateway, domain controller, safety co-processor and expansion options to include additional perception and acceleration solutions.
製品詳細
Features
BlueBox 3.0 Features
- True automotive embedded platform featuring end-to-end automotive-grade system-on-chip ICs
-
Modular and scalable open platform supporting rich expansion options to prototype various configurations and connections to multiple ECUs and sensors:
- Up to 6 PCIe® expansion slots
- Up to 8 Ethernet ports
-
System-level safety implementation with the device-level safety collaterals:
- ASIL D subsystem, with dedicated interfaces
- ASIL B compute, automotive interfaces with vision acceleration
- S32G274A vehicle network processor with ASIL D functional safety
- High-performance LX2160A automotive processor with 16 Arm® Cortex®-A72 cores
- SJA1110 automotive Ethernet switch with TSN support
- 12 V / 24 V vehicle compatible power input
- 16 GB DDR4 and 256 GB SSD
- Ethernet 100M/1G/10Gbps, SFP+, 8 x 100BASE-T1, CAN-FD, FlexRay™, 8 x cameras
Development Partners
ドキュメント
クイック・リファレンス ドキュメンテーションの種類.
4 ドキュメント
-
ファクト・シート
S32G車載ネットワーク・プロセッサ – ファクト･シート
-
ファクト・シート
SJA1110車載イーサネット・スイッチ
-
ファクト・シート
NXP Blue Box 3.0 – Fact Sheet
設計・リソース
ソフトウェア
クイック・リファレンス ソフトウェア・タイプ.
3 ソフトウェア・ファイル
-
BSPとデバイスドライバ
BSP for S32 Microcontrollers and Processors
-
BSPとデバイスドライバ
Automotive SW for S32V234 – Linux BSP
-
セーフティ＆セキュリティ・ソフトウェア
S32セーフティ・ソフトウェア・フレームワーク (SAF) およびセーフティ・ペリフェラル・ドライバ (SPD)
注: より快適にご利用いただくために、ソフトウェアのダウンロードはデスクトップで行うことを推奨します。
