Ultra-Low-Power, Highly Integrated MCU

K32-L2 アクティブ
Ultra-Low Power K32 L Series MCUs Optimized for Low-leakage Applications

動画の上をクリックすると再生されます。

The K32 L2 MCU family’s low-leakage architecture, combined with its power-optimized peripherals and security features (such as cryptographic acceleration technology, cyclic redundancy check and a true random number generator), make it ideal for consumer, industrial and IoT applications requiring a low-priced, power efficient option with longer battery life.

This family includes a low power Arm® Cortex®-M0+ core and with options scaling from 64 KB to 512 KB Flash and from 32 kB to 128 kB SRAM, the K32 L2 family offers a wide range of memory resources to fit different application tasks within a small-form factor, low power, and highly integrated design.

ブロック図

K32 L2 MCU

K32 L2 MCU
図を取得する PDF

Features

Ultra Low-Power

  • Low-power Arm® Cortex®-M0+ core
  • Multiple low-power modes enabling the reduction of dynamic power consumption
  • Low-power serial peripheral interfaces supporting low-power operation modes without waking up the core

On-Chip Memory

  • 64 – 512 KB Flash Memory
  • 32 – 128 KB SRAM Memory
  • 16 – 32 KB ROM Memory with integrated bootloader

Connectivity and Communications

  • USB 2.0 Full Speed integrated with low-voltage regulator
  • 4-8 channel DMA for peripheral and memory servicing with reduced CPU loading
  • Up to three I2C, up to three LPUART and up to three SPI serial interfaces with DMA support
  • FlexIO interface with capability of emulating multiple serial interfaces
  • Segment LCD supporting up to 24x8 or 28x4 segments*

Mixed-Signal

  • 16-bit ADC module with high accuracy internal voltage reference (Vref)
  • Up to two High-speed analog comparator containing a 6-bit DAC for programmable reference input
  • One 12-bit DAC
  • 1.2/2.1 V internal voltage reference

Timers

  • One 6-channel Timer/PWM module-
  • Two 2-channel Timer/PWM modules
  • Up to two low-power timer
  • Up to two Periodic interrupt timer
  • Real time clock

Human Machine Interface (HMI)

  • Capacitive touch sense interface supporting up to 16 external electrodes**
  • GPIO with pin interrupt support

Security**

  • Cryptographic acceleration unit supporting acceleration of DES, 3DES, AES, MD5, SHA-1 and SHA-256 algorithms
  • Hardware accelerated True Random Number Generator

もっと見る

購入/パラメータ

1-10 の 16 結果

マッチしていない 0 NRND

パーツ

説明を表示

注文

コンピュータ支援設計 モデル

状況

標準価格

コア・タイプ

動作周波数[最大](MHz)

Flash (kB)

SRAM (kB)

Serial Communication

USB Type

ADC [Number, bits]

汎用I/O

電源電圧 [最小 - 最大] (V)

Ambient Operating Temperature (Min to Max) (℃)

パッケージタイプ

Package Pitch (mm)

K32L2A31VLH1A
データ・シート

アクティブ

10K @ US$2.24

1 x Arm Cortex-M0+

72

256

128

—

—

1 x 16

50

1.71 to 3.6

-40 to 105

LQFP64

0.5

K32L2A31VLL1A
データ・シート

アクティブ

10K @ US$2.40

1 x Arm Cortex-M0+

72

256

128

—

—

1 x 16

86

1.71 to 3.6

-40 to 105

LQFP100

0.5

K32L2A41VLH1A
データ・シート

アクティブ

10K @ US$2.59

1 x Arm Cortex-M0+

72

512

128

—

—

1 x 16

50

1.71 to 3.6

-40 to 105

LQFP64

0.5

K32L2A41VLL1A
データ・シート

アクティブ

10K @ US$2.75

1 x Arm Cortex-M0+

72

512

128

—

—

1 x 16

86

1.71 to 3.6

-40 to 105

LQFP100

0.5

K32L2B11VFM0A
データ・シート

アクティブ

10K @ US$1.22

1 x Arm Cortex-M0+

48

64

32

1 x UART w/ ISO-7816, 2 x I²C, 2 x SPI

—

1 x 16

23

1.71 to 3.6

-40 to 105

HUQFN32

0.5

K32L2B11VFT0A
データ・シート

アクティブ

10K @ US$1.29

1 x Arm Cortex-M0+

48

64

32

1 x UART w/ ISO-7816, 2 x I²C, 2 x SPI

—

1 x 16

36

1.71 to 3.6

-40 to 105

HUQFN48

0.5

K32L2B11VLH0A
データ・シート

アクティブ

10K @ US$1.37

1 x Arm Cortex-M0+

48

64

32

1 x UART w/ ISO-7816, 2 x I²C, 2 x SPI

—

1 x 16

50

1.71 to 3.6

-40 to 105

LQFP64

0.5

K32L2B11VMP0A
データ・シート

アクティブ

10K @ US$1.34

1 x Arm Cortex-M0+

48

64

32

1 x UART w/ ISO-7816, 2 x I²C, 2 x SPI

—

1 x 16

50

1.71 to 3.6

-40 to 105

LFBGA64

0.5

K32L2B21VFM0A
データ・シート

アクティブ

10K @ US$1.45

1 x Arm Cortex-M0+

48

128

32

1 x UART w/ ISO-7816, 2 x I²C, 2 x SPI

—

1 x 16

23

1.71 to 3.6

-40 to 105

HUQFN32

0.5

K32L2B21VFT0A
データ・シート

アクティブ

10K @ US$1.55

1 x Arm Cortex-M0+

48

128

32

1 x UART w/ ISO-7816, 2 x I²C, 2 x SPI

—

1 x 16

36

1.71 to 3.6

-40 to 105

HUQFN48

0.5
