Ultra-Reliable 32-bit MCU for Automotive ADAS and Industrial Ethernet Applications

MPC560xE アクティブ
Qorivva MPC5604 MCU and i.MX6 Park Assist

動画の上をクリックすると再生されます。

The MPC560xE family of MCUs enables advanced driver assistance, surround-view, camera-based systems, and industrial applications. MPC560xE MCUs are gateway systems, designed to move data from different sources via Ethernet to a receiving system and vice-versa.

MPC560xE MCUs allow for greater levels of system integration, also helps to enable the miniaturization of camera modules while reducing system costs and time-to-market.

MPC560xE MCUs offers a comprehensive development toolset, designed to simplify and accelerate system design: MPC5604ES includes a software license package consisting of Ethernet streaming and camera application software as well as AUTOSAR® OS.

Disclaimer: Please contact your local NXP sales representative or a NXP authorized distributor to get access to the software.

ブロック図

MPC560XE block diagram

MPC560XE block diagram
図を取得する PDF

Features

Specifications

  • 64 MHz NXP® e200 zen0h core

Memory

  • 512k byte Program Flash with ECC
  • 4x16k byte Data Flash with ECC
  • 96k byte SRAM with ECC

I/O

  • 1 x MJPEG® video encoder with image sensor interface supporting up to 1.2MPixel
  • 1 x 10/100 Ethernet MAC incl. IEEE 1588 PTP support
  • BCM89810 BroadR-Reach® compatible phy (MPC5606E only)
  • FlexCAN, LINFlex
  • 5V ADC

System

  • 3.3V single supply
  • 64 pin LQFP package

購入/パラメータ

5 結果

マッチしていない 0 NRND

パーツ

説明を表示

注文

コンピュータ支援設計 モデル

状況

パッケージタイプ

パッケージ端子数

標準価格

Flash (kB)

RAM (kB)

コア・タイプ

コア：コア数 - 仕様

動作周波数[最大](MHz)

安全保障機能安全

I2C

CAN

SCI

DSPI

Ambient Operating Temperature (Min to Max) (℃)

電源電圧 [最小] (V)

電源電圧 [最大] (V)

SPC5604EEF2MLH
データ・シート

アクティブ

LQFP64

64

10K @ US$11.12 - 10K @ US$11.48

512

96

e200

1

64

No

2

1

2

3

-40 to 125

1.2

3.3

SPC5604ESF2MLH
データ・シート

アクティブ

LQFP64

64

10K @ US$13.36

512

96

e200

1

64

No

2

1

2

3

-40 to 125

1.2

3.3

SPC5604ESF2VLH
データ・シート

アクティブ

LQFP64

64

10K @ US$12.70

512

96

e200

1

64

No

2

1

2

3

-40 to 125

1.2

3.3

SPC5606EEF2VMC
データ・シート

アクティブ

LFBGA121

121

10K @ US$19.35 - 10K @ US$19.74

512

96

e200

1

64

No

2

1

2

3

-40 to 125

1.2

3.3

SPC5606EF2VMC
データ・シート

アクティブ

LFBGA121

121

10K @ US$18.69 - 10K @ US$19.07

512

96

e200

1

64

No

2

1

2

3

-40 to 125

1.2

3.3

N true 0 PSPMPC560xEja 39 アプリケーション・ノート Application Note t789 16 アプリケーション・ノート・ソフトウェア Application Note Software t783 1 エラッタ Errata t522 5 エンジニアリング・ブリテン Technical Notes t521 6 データ・シート Data Sheet t520 2 ファクト・シート Fact Sheet t523 2 ユーザ・ガイド User Guide t792 2 リファレンス・マニュアル Reference Manual t877 3 製品概要 Product Brief t532 2 ja 5 1 1 English Explaining how to connect a video device to the MPC5604E MCU and configure the MPC5604E Video Encoder Wrapper correctly to get MJPEG video stream from your YUV422 video data. 1334140358906726190760 PSP 408.0 KB None None documents None 1334140358906726190760 /docs/en/application-note/AN4514.pdf 407986 /docs/en/application-note/AN4514.pdf AN4514 N N 2021-07-21 AN4514: MPC5604E Video Encoder Wrapper – Application Note /docs/en/application-note/AN4514.pdf /docs/en/application-note/AN4514.pdf Application Note N Y 645036621402383989 2022-12-07 pdf N en May 6, 2012 Application Note t789 アプリケーション・ノート Application Note Y N AN4514: MPC5604E Video Encoder Wrapper – Application Note 2 6 English MPC5604E: This document provides electrical specifications, pin assignments, and package diagrams for the MPC5604E series of microcontroller units (MCUs). 1308040802351722232495 PSP 1.0 MB None None documents None 1308040802351722232495 /docs/en/data-sheet/MPC5604E.pdf 1036307 /docs/en/data-sheet/MPC5604E.pdf MPC5604E N N 2020-03-02 MPC5604E Microcontroller Data Sheet /docs/en/data-sheet/MPC5604E.pdf /docs/en/data-sheet/MPC5604E.pdf Data Sheet N Y 980000996212993340 2022-12-07 pdf N en Mar 2, 2020 Data Sheet t520 データ・シート Data Sheet Y N MPC5604E Microcontroller Data Sheet 3 0 English The Qorivva MPC5606E MCU family is built on Power Architecture® technology designed for automotive video compression and transmission over Ethernet and ideal for camera-based ADAS surround view and park assist applications. 1395701531068705748739 PSP 448.1 KB None None documents None 1395701531068705748739 /docs/en/fact-sheet/MPC5606EFS.pdf 448130 /docs/en/fact-sheet/MPC5606EFS.pdf MPC5606EFS N N 2016-10-31 Freescale MPC5606E MCU - Fact Sheet /docs/en/fact-sheet/MPC5606EFS.pdf /docs/en/fact-sheet/MPC5606EFS.pdf Fact Sheet N Y 736675474163315314 2022-12-07 pdf N en Mar 24, 2014 Fact Sheet t523 ファクト・シート Fact Sheet Y N Freescale MPC5606E MCU - Fact Sheet 4 SPC5606EEF2VMC,SPC5606EF2VMC 4 English MPC5606E: This document provides electrical specifications, pin assignments, and package diagrams for the MPC5606E series of microcontroller units (MCUs). This document describes the features of the family and options available within the family members, and highlights important electrical and physical characteristics of the devices.

 1408542755635715750496 PSP 1.5 MB None None documents None 1408542755635715750496 /docs/en/data-sheet/MPC5606E.pdf 1462493 /docs/en/data-sheet/MPC5606E.pdf MPC5606E N N 2020-03-02 MPC5606E, MPC5606E Microcontroller Data Sheet - Data Sheet /docs/en/data-sheet/MPC5606E.pdf /docs/en/data-sheet/MPC5606E.pdf Data Sheet N Y 980000996212993340 2022-12-07 pdf N en Sep 21, 2020 Data Sheet t520 データ・シート Data Sheet Y N MPC5606E, MPC5606E Microcontroller Data Sheet - Data Sheet 5 5 English This reference manual describes the MPC5604E processor for software and hardware developers.
 1321009215715725642934 PSP 16.1 MB Registration without Disclaimer None documents Extended 1321009215715725642934 /secured/assets/documents/en/reference-manual/MPC5604ERM.pdf 16105718 /secured/assets/documents/en/reference-manual/MPC5604ERM.pdf MPC5604ERM Y N 2016-10-31 MPC5604E Microcontroller Reference Manual /webapp/Download?colCode=MPC5604ERM&docLang=en /secured/assets/documents/en/reference-manual/MPC5604ERM.pdf Reference Manual N Y 500633505221135046 2023-06-18 pdf Y en Jul 30, 2015 Reference Manual t877 リファレンス・マニュアル Reference Manual Y N MPC5604E Microcontroller Reference Manual true ja ja リファレンス・マニュアル Reference Manual 2 6 2 English MPC5606ERM: This reference manual describes the MPC5604E processor for software and hardware developers. The MPC5606E microcontroller is a gateway system designed to move data from different sources. 1408540963296699412730 PSP 16.1 MB Registration without Disclaimer None documents Extended 1408540963296699412730 /secured/assets/documents/en/reference-manual/MPC5606ERM.pdf 16060753 /secured/assets/documents/en/reference-manual/MPC5606ERM.pdf MPC5606ERM documents Y N 2016-10-31 MPC5606ERM: MPC5606E Microcontroller Reference Manual /webapp/Download?colCode=MPC5606ERM&lang_cd=ja /secured/assets/documents/en/reference-manual/MPC5606ERM.pdf Reference Manual N 500633505221135046 2022-12-07 pdf Y en Aug 20, 2014 500633505221135046 Reference Manual Y N MPC5606ERM: MPC5606E Microcontroller Reference Manual 7 1.0-2 English SPE2PIM - Help programmers provide software that is compatible across the family of processors that use the enhanced signal processing (SPE2) and embedded floating-point version-2 (EFP2) auxiliary processing unit (APU) extension. 1312437745440709015400 PSP 24.8 MB Registration without Disclaimer None documents Extended 1312437745440709015400 /secured/assets/documents/en/reference-manual/SPE2PIM.pdf 24767945 /secured/assets/documents/en/reference-manual/SPE2PIM.pdf SPE2PIM documents Y N 2016-10-31 SPE2PIM - Enhanced Signal Processing Extension and Embedded Floating-Point Version 2 Auxiliary Processing Units Programming Interface Manual /webapp/Download?colCode=SPE2PIM&lang_cd=ja /secured/assets/documents/en/reference-manual/SPE2PIM.pdf Reference Manual N 500633505221135046 2022-12-07 pdf Y en Aug 3, 2013 500633505221135046 Reference Manual Y N SPE2PIM - Enhanced Signal Processing Extension and Embedded Floating-Point Version 2 Auxiliary Processing Units Programming Interface Manual アプリケーション・ノート Application Note 15 8 0 Chinese Reviewing the troubleshoot microcontroller when there is a malfunction module. 1641302649210707506203zh PSP 303.0 KB None None documents None 1641302649210707506203 /docs/zh/application-note/AN13461.pdf 302971 /docs/zh/application-note/AN13461.pdf AN13461 documents N N 2022-01-04 AN13461: NXP Microcontroller Troubleshooting Checklist - Application Note /docs/zh/application-note/AN13461.pdf /docs/zh/application-note/AN13461.pdf Application Note N 645036621402383989 2022-12-07 zh May 9, 2022 645036621402383989 Application Note Y N 恩智浦微控制器故障排除清单 0 English Reviewing the troubleshoot microcontroller when there is a malfunction module. 1641302649210707506203 PSP 303.0 KB None None documents None 1641302649210707506203 /docs/en/application-note/AN13461.pdf 302971 /docs/en/application-note/AN13461.pdf AN13461 documents N N 2022-01-04 AN13461: NXP Microcontroller Troubleshooting Checklist - Application Note /docs/en/application-note/AN13461.pdf /docs/en/application-note/AN13461.pdf Application Note N 645036621402383989 2022-12-07 pdf N en Nov 30, 2021 645036621402383989 Application Note Y N AN13461: NXP Microcontroller Troubleshooting Checklist - Application Note 9 0 English AN12080SW.zip /docs/en/application-note-software/AN12080SW.zip /docs/en/application-note-software/AN12080SW.zip Guiding on how to initialize the Clock Monitor Unit (CMU) on MPC56xx and MPC57xx microcontrollers. The majority of the MPC56xx and MPC57xx parts have more than one CMU unit. The device has a CMU_0 capable of measuring the IRCOSC, XOSC monitoring, and monitoring one of the other system clocks. The device then contains other CMU_n blocks that are capable of monitoring other important system clocks. 1511852813679719749243 PSP 196.6 KB None None documents None 1511852813679719749243 /docs/en/application-note/AN12080.pdf 196599 /docs/en/application-note/AN12080.pdf AN12080 documents N N 2017-11-28 AN12080: The Clock Monitor Unit (CMU) – Application Note /docs/en/application-note/AN12080.pdf /docs/en/application-note/AN12080.pdf Application Note N 645036621402383989 2022-12-07 pdf N en Nov 27, 2017 645036621402383989 Application Note Y N AN12080: The Clock Monitor Unit (CMU) – Application Note 10 0 English Describing the proper method to initialize and change the frequency of the Frequency Modulated Phase Lock Loop (FMPLL) module for the MPC564xA and MPC563xM families of devices. The FMPLL allows the users to generate high-speed system clocks from a crystal oscillator or an external clock generator and supports programmable frequency modulation (FM) of the system clock. 1493874951081708875046 PSP 178.7 KB None None documents None 1493874951081708875046 /docs/en/application-note/AN11960.pdf 178663 /docs/en/application-note/AN11960.pdf AN11960 documents N N 2017-05-03 AN11960: MPC564xA/MPC563xM FMPLL Initialization – Application Note /docs/en/application-note/AN11960.pdf /docs/en/application-note/AN11960.pdf Application Note N 645036621402383989 2022-12-07 pdf N en May 3, 2017 645036621402383989 Application Note Y N AN11960: MPC564xA/MPC563xM FMPLL Initialization – Application Note 11 2 English Describing the basic principles behind using MPC5xxx flash memory for EEPROM emulation, and provides some insight on the functionality of NXP EEPROM emulation drivers. Although MPC55xx, MPC56xx, and MPC57xx MCUs do not include EEPROM, the functionality of this memory type can be emulated with the flash memory that is available. 1390573644054723435374 PSP 498.5 KB None None documents None 1390573644054723435374 /docs/en/application-note/AN4868.pdf 498534 /docs/en/application-note/AN4868.pdf AN4868 documents N N 2017-03-03 AN4868: EEPROM Emulation with MPC55xx, MPC56xx, and MPC57xx Microcontrollers – Application Note /docs/en/application-note/AN4868.pdf /docs/en/application-note/AN4868.pdf Application Note N 645036621402383989 2022-12-07 pdf N en Mar 2, 2017 645036621402383989 Application Note Y N AN4868: EEPROM Emulation with MPC55xx, MPC56xx, and MPC57xx Microcontrollers – Application Note 12 1 English Outlining how Error-Correcting Codes (ECC) protection is implemented with MPC55xx and MPC56xx devices and understand particular MCU’s ECC event response. Also offering some software examples for illustration of mentioned behavior. 1443422519227696132934 PSP 928.6 KB None None documents None 1443422519227696132934 /docs/en/application-note/AN5200.pdf 928642 /docs/en/application-note/AN5200.pdf AN5200 documents N N 2021-07-21 AN5200: Error-Correcting Codes Implemented on MPC55xx and MPC56xx – Application Note /docs/en/application-note/AN5200.pdf /docs/en/application-note/AN5200.pdf Application Note N 645036621402383989 2022-12-07 pdf N en Dec 10, 2015 645036621402383989 Application Note Y N AN5200: Error-Correcting Codes Implemented on MPC55xx and MPC56xx – Application Note 13 0 English AN5100: This document provides information about designing automotive board with MPC5606E. It details the key design consideration, the PCB layout and components selection. 1433918705754705848114 PSP 1.3 MB None None documents None 1433918705754705848114 /docs/en/application-note/AN5100.pdf 1288074 /docs/en/application-note/AN5100.pdf AN5100 documents N N 2015-06-09 AN5100, MPC5606E: Design for Performance and Electromagnetic Compatibility – Application notes /docs/en/application-note/AN5100.pdf /docs/en/application-note/AN5100.pdf Application Note N 645036621402383989 2022-12-07 pdf N en Jun 9, 2015 645036621402383989 Application Note N N AN5100, MPC5606E: Design for Performance and Electromagnetic Compatibility – Application notes 14 2 English Presenting simple semaphore routines (with C code, followed by a detailed explanation of its functionality) that lock, unlock, and reset semaphore gates (flags) on MCP56xx and MPC57xx MCUs. These routines are non-blocking and reentrant functions suitable for multi-core application usage. 1378914456666698383839 PSP 326.0 KB None None documents None 1378914456666698383839 /docs/en/application-note/AN4805.pdf 326038 /docs/en/application-note/AN4805.pdf AN4805 documents N N 2021-07-21 AN4805: A Practical Approach to Hardware Semaphores – Application Note /docs/en/application-note/AN4805.pdf /docs/en/application-note/AN4805.pdf Application Note N 645036621402383989 2022-12-07 pdf N en Jan 12, 2014 645036621402383989 Application Note Y N AN4805: A Practical Approach to Hardware Semaphores – Application Note 15 0 English Guiding how to configure the eTPU2 for T2/T4 Channel Timing. The Enhanced Time Processing Unit (eTPU) is a programmable I/O controller with its core and memory system, allowing it to perform complex timing and I/O management independently of the CPU. 1382000248406719941156 PSP 226.8 KB None None documents None 1382000248406719941156 /docs/en/application-note/AN4756.pdf 226756 /docs/en/application-note/AN4756.pdf AN4756 documents N N 2021-07-21 AN4756: eTPU2 Time Base Running at Full Speed – Application Note /docs/en/application-note/AN4756.pdf /docs/en/application-note/AN4756.pdf Application Note N 645036621402383989 2022-12-07 pdf N en Oct 16, 2013 645036621402383989 Application Note Y N AN4756: eTPU2 Time Base Running at Full Speed – Application Note 16 1 English Providing instructions for creating an application program that is capable of uploading the application program to the SoC via the Boot Assist Module (BAM) Enhanced Serial Communication Interface (ESCI) and the Controller Area Network interface (CAN) interface, in either fixed baud rate mode or automatic baud rate detection mode. 1360821858350706869722 PSP 891.0 KB None None documents None 1360821858350706869722 /docs/en/application-note/AN4674.pdf 891044 /docs/en/application-note/AN4674.pdf AN4674 documents N N 2021-07-21 AN4674: MPC5xxx Boot Assist Module Application – Application Note /docs/en/application-note/AN4674.pdf /docs/en/application-note/AN4674.pdf Application Note N 645036621402383989 2022-12-07 pdf N en Jun 30, 2013 645036621402383989 Application Note Y N AN4674: MPC5xxx Boot Assist Module Application – Application Note 17 0 English Explaining how to add the FreeMASTER serial driver software to the embedded application and configure it. The FreeMASTER serial driver is a piece of code that enables an embedded application to communicate with the FreeMASTER PC application. 1370013855832696188368 PSP 2.2 MB Registration without Disclaimer None documents Extended 1370013855832696188368 /secured/assets/documents/en/application-note/AN4752.pdf 2220944 /secured/assets/documents/en/application-note/AN4752.pdf AN4752 documents Y N 2016-10-31 AN4752: FreeMASTER Usage, Serial Driver Implementation – Application Note /webapp/Download?colCode=AN4752&lang_cd=ja /secured/assets/documents/en/application-note/AN4752.pdf Application Note N 645036621402383989 2024-07-15 pdf Y en May 31, 2013 645036621402383989 Application Note Y N AN4752: FreeMASTER Usage, Serial Driver Implementation – Application Note 18 0 English Presenting the use of the Rational ClearCase version control system in CodeWarrior 10.3. It lists the files needed to maintain the project and describes how to install, set up, use, and uninstall the ClearCase plugin in CodeWarrior 10.3. The ClearCase plugin enables you to check files in and out directly from within CodeWarrior, making the work more effective. 1369937932059742568603 PSP 477.3 KB None None documents None 1369937932059742568603 /docs/en/application-note/AN4753.pdf 477314 /docs/en/application-note/AN4753.pdf AN4753 documents N N 2016-10-31 AN4753: Rational ClearCase Use in CodeWarrior 10.3 – Application Note /docs/en/application-note/AN4753.pdf /docs/en/application-note/AN4753.pdf Application Note N 645036621402383989 2024-07-15 pdf N en May 30, 2013 645036621402383989 Application Note Y N AN4753: Rational ClearCase Use in CodeWarrior 10.3 – Application Note 19 1 English Describing a method for decoding the length of VLE instructions is used to increment the returning address of the exception correctly. 1357316370579707941955 PSP 258.2 KB None None documents None 1357316370579707941955 /docs/en/application-note/AN4648.pdf 258179 /docs/en/application-note/AN4648.pdf AN4648 documents N N 2021-07-21 AN4648: VLE 16-bit and 32-bit Instruction Length Decode Algorithm – Application Note /docs/en/application-note/AN4648.pdf /docs/en/application-note/AN4648.pdf Application Note N 645036621402383989 2022-12-07 pdf N en Mar 21, 2013 645036621402383989 Application Note Y N AN4648: VLE 16-bit and 32-bit Instruction Length Decode Algorithm – Application Note 20 0 English Showing how the MPC5604E SAI can be easily configured for any audio converter. Connecting audio devices to the MPC5604E is an easy task for the MPC5604E Serial Audio Interface (SAI). 1331272174444711826479 PSP 682.1 KB None None documents None 1331272174444711826479 /docs/en/application-note/AN4486.pdf 682083 /docs/en/application-note/AN4486.pdf AN4486 documents N N 2021-07-21 AN4486: MPC5604E Serial Audio Interface – Application Note /docs/en/application-note/AN4486.pdf /docs/en/application-note/AN4486.pdf Application Note N 645036621402383989 2022-12-07 pdf N en Mar 8, 2012 645036621402383989 Application Note Y N AN4486: MPC5604E Serial Audio Interface – Application Note 21 0 English Describing possible hardware considerations for developing hardware design solutions. It covers topics such as clock generation, decoupling, and voltage regulator, and power considerations. 1326135258624733883664 PSP 910.1 KB None None documents None 1326135258624733883664 /docs/en/application-note/AN4433.pdf 910067 /docs/en/application-note/AN4433.pdf AN4433 documents N N 2021-07-21 AN4433: MPC5604E Hardware Design Guide – Application Note /docs/en/application-note/AN4433.pdf /docs/en/application-note/AN4433.pdf Application Note N 645036621402383989 2022-12-07 pdf N en Jan 9, 2012 645036621402383989 Application Note Y N AN4433: MPC5604E Hardware Design Guide – Application Note 22 0 English Showing how to develop a flash memory programming tool for the MPC56xx family of devices. Giving some details about the JTAG communication protocol, OnCE module, or the Nexus R/W access block. 1316629672453740598962 PSP 1.5 MB None None documents None 1316629672453740598962 /docs/en/application-note/AN4365.pdf 1527214 /docs/en/application-note/AN4365.pdf AN4365 documents N N 2021-07-21 AN4365: MPC56xx Flash Programming Through Nexus/JTAG – Application Note /docs/en/application-note/AN4365.pdf /docs/en/application-note/AN4365.pdf Application Note N 645036621402383989 2022-12-07 pdf N en Sep 21, 2011 645036621402383989 Application Note Y N AN4365: MPC56xx Flash Programming Through Nexus/JTAG – Application Note ユーザ・ガイド User Guide 2 23 2 English MPC5606EBUG: This document evaluates MPC5606E Evaluation Board (EVB) that is based on the e200z0 Power Architecture core. The MPC5606E 121-pin MAPBGA is assembled on this board to allow the evaluation of the full functionality of this part.?? 1395956692128704082902 PSP 492.1 KB None None documents None 1395956692128704082902 /docs/en/user-guide/MPC5606EBUG.pdf 492133 /docs/en/user-guide/MPC5606EBUG.pdf MPC5606EBUG documents N N 2014-04-04 MPC5606EBUG, MPC5606E Board User Guide - User Guide /docs/en/user-guide/MPC5606EBUG.pdf /docs/en/user-guide/MPC5606EBUG.pdf User Guide N 132339537837198660 2023-06-18 pdf N en Apr 8, 2014 132339537837198660 User Guide Y N MPC5606EBUG, MPC5606E Board User Guide - User Guide 24 0 English The MPC5604EEVB64 Evaluation Board (EVB) is
based on the e200z0 Power Architecture®. This board is shipped with the PPC5604EEMLH 64-pin LQFP MCU populated to allow the evaluation of the full functionality of this part. 1318500737841712455929 PSP 1.9 MB None None documents None 1318500737841712455929 /docs/en/user-guide/MPC5604EEVB64UM.pdf 1850697 /docs/en/user-guide/MPC5604EEVB64UM.pdf MPC5604EEVB64UM documents N N 2011-10-13 MPC5604EEVB64 Evaluation board User Manual /docs/en/user-guide/MPC5604EEVB64UM.pdf /docs/en/user-guide/MPC5604EEVB64UM.pdf User Guide N 132339537837198660 2023-06-18 pdf N en Oct 12, 2011 132339537837198660 User Guide Y N MPC5604EEVB64 Evaluation board User Manual アプリケーション・ノート・ソフトウェア Application Note Software 1 25 0 English AN12080SW, A part's clocks are critical to its safe operation. They need to be accurate and correctly programmed and if there is any variation in their frequency then the application should be notified. 1511782984892715412544 PSP 252.0 KB None None documents None 1511782984892715412544 /docs/en/application-note-software/AN12080SW.zip 251963 /docs/en/application-note-software/AN12080SW.zip AN12080SW documents N N 2017-11-24 Software for AN12080 /docs/en/application-note-software/AN12080SW.zip /docs/en/application-note-software/AN12080SW.zip Application Note Software N 789425793691620447 2022-12-07 zip N en Nov 26, 2017 789425793691620447 Application Note Software Y N Software for AN12080 エンジニアリング・ブリテン Technical Notes 6 26 0 English EB00877, This engineering bulletin provides guidance on programming Priority(PRI) bits of the Interrupt Controller Current Priority Register(INTC_CPRn[PRI]) to ensure coherency of shared resource between Interrupt Services Routines(ISRs) for the MPC56xx and MPC57xx family of devices. 1550136400774719898938 PSP 131.8 KB None None documents None 1550136400774719898938 /docs/en/engineering-bulletin/EB00877.pdf 131838 /docs/en/engineering-bulletin/EB00877.pdf EB00877 documents N N 2019-02-14 EB00877, Programming Priority Bits in the Interrupt Controller Current Priority Register for MPC56xx and MPC57xx Families /docs/en/engineering-bulletin/EB00877.pdf /docs/en/engineering-bulletin/EB00877.pdf Technical Notes N 389245547230346745 2022-12-07 pdf N en Feb 13, 2019 389245547230346745 Technical Notes Y N EB00877, Programming Priority Bits in the Interrupt Controller Current Priority Register for MPC56xx and MPC57xx Families 27 0 English EB00855, This engineering bulletin provides guidance on programming reserved register bits for the MPC55xx, MPC56xx, and MPC57xx families of devices. 1495699633841705738852 PSP 162.7 KB None None documents None 1495699633841705738852 /docs/en/engineering-bulletin/EB00855.pdf 162731 /docs/en/engineering-bulletin/EB00855.pdf EB00855 documents N N 2017-05-25 EB00855, Programming Reserved Register Bits for MPC55xx, MPC56xx, and MPC57xx Families /docs/en/engineering-bulletin/EB00855.pdf /docs/en/engineering-bulletin/EB00855.pdf Technical Notes N 389245547230346745 2022-12-07 pdf N en May 24, 2017 389245547230346745 Technical Notes N EB00855, Programming Reserved Register Bits for MPC55xx, MPC56xx, and MPC57xx Families 28 0 English EB795:This document aims to describe Errata 7026 which affect the MPC564xS devices and how to safely handle it. 1378092305734717489368 PSP 409.2 KB None None documents None 1378092305734717489368 /docs/en/engineering-bulletin/EB795.pdf 409249 /docs/en/engineering-bulletin/EB795.pdf EB795 documents N N 2013-09-01 EB795, Working around ERR7026 according to application needs - Engineering Bulletin /docs/en/engineering-bulletin/EB795.pdf /docs/en/engineering-bulletin/EB795.pdf Technical Notes N 389245547230346745 2022-12-07 pdf N en Aug 30, 2013 389245547230346745 Technical Notes Y N EB795, Working around ERR7026 according to application needs - Engineering Bulletin 29 1 English EB793: This document, developed in response to customer inquiries, describes Motor Industry Software Reliability Association (MISRA™) compliance in the C Language header files provided by NXP for the automotive market. 1369851108709706895647 PSP 197.0 KB Registration without Disclaimer None documents Extended 1369851108709706895647 /secured/assets/documents/en/engineering-bulletin/EB793.pdf 197012 /secured/assets/documents/en/engineering-bulletin/EB793.pdf EB793 documents Y N 2016-10-31 MISRA Compliance in Freescale Automotive C Language Header Files - Engineering Bulletin /webapp/Download?colCode=EB793&lang_cd=ja /secured/assets/documents/en/engineering-bulletin/EB793.pdf Technical Notes N 389245547230346745 2024-07-15 pdf Y en May 28, 2013 389245547230346745 Technical Notes Y N MISRA Compliance in Freescale Automotive C Language Header Files - Engineering Bulletin 30 1 English The purpose of this engineering bulletin is to describe how to apply errata 4080 to MPC5604E Evaluation Board. This errata describe issue where device cannot come out of reset till VDD_LV is less than a threshold value. This document is valid for evaluation boards where device with mask 0N10D is installed and board is not marked with a TDA4008 label. 1325584485811732432483 PSP 180.1 KB None None documents None 1325584485811732432483 /docs/en/engineering-bulletin/EVB772.pdf 180086 /docs/en/engineering-bulletin/EVB772.pdf EB772 documents N N 2012-01-03 Applying Errata ID 4080 to MPC5604E Evaluation Board /docs/en/engineering-bulletin/EVB772.pdf /docs/en/engineering-bulletin/EVB772.pdf Technical Notes N 389245547230346745 2022-12-07 pdf N en Jan 2, 2012 389245547230346745 Technical Notes Y N Applying Errata ID 4080 to MPC5604E Evaluation Board 31 0 English This document describes how to use Qorivva header files in the C programming language. It highlights the instructions generated by C compilers and discusses the related consequences for the MCU’s hardware. 1318598668663692344265 PSP 323.7 KB None None documents None 1318598668663692344265 /docs/en/engineering-bulletin/EB758.pdf 323744 /docs/en/engineering-bulletin/EB758.pdf EB758 documents N N 2011-10-14 Using MPC5xxx Header Files In C /docs/en/engineering-bulletin/EB758.pdf /docs/en/engineering-bulletin/EB758.pdf Technical Notes N 389245547230346745 2022-12-07 pdf N en Oct 10, 2011 389245547230346745 Technical Notes Y N Using MPC5xxx Header Files In C エラッタ Errata 5 32 10 NOV 2014 English MPC5604E_2N10D, This report applies to mask 2N10D for MPC5604E 1415696681909706249903 PSP 95.2 KB None None documents None 1415696681909706249903 /docs/en/errata/MPC5604E_2N10D.pdf 95178 /docs/en/errata/MPC5604E_2N10D.pdf MPC5604E_2N10D documents N N 2014-11-11 MPC5604E_2N10D, Mask Set Errata for Mask 2N10D /docs/en/errata/MPC5604E_2N10D.pdf /docs/en/errata/MPC5604E_2N10D.pdf Errata N 155452329886410597 2022-12-07 pdf N en Nov 10, 2014 155452329886410597 Errata Y N MPC5604E_2N10D, Mask Set Errata for Mask 2N10D 33 10 NOV 2014 English MPC5604E_1N10D: This report applies to mask 1N10D for MPC5604E 1415696211817714495518 PSP 95.7 KB None None documents None 1415696211817714495518 /docs/en/errata/MPC5604E_1N10D.pdf 95721 /docs/en/errata/MPC5604E_1N10D.pdf MPC5604E_1N10D documents N N 2014-11-11 MPC5604E_1N10D, Mask Set Errata for Mask 1N10D /docs/en/errata/MPC5604E_1N10D.pdf /docs/en/errata/MPC5604E_1N10D.pdf Errata N 155452329886410597 2022-12-07 pdf N en Nov 10, 2014 155452329886410597 Errata Y N MPC5604E_1N10D, Mask Set Errata for Mask 1N10D 34 Rev 28 JUL 2014 English MPC5606E_2N10D: This errata presents information about Mask Set Errata for Mask 2N10D. 1406877130880694181806 PSP 99.2 KB None None documents None 1406877130880694181806 /docs/en/errata/MPC5606E_2N10D.pdf 99183 /docs/en/errata/MPC5606E_2N10D.pdf MPC5606E_2N10D documents N N 2014-08-01 MPC5606E_2N10D, Mask Set Errata for Mask 2N10D – Errata /docs/en/errata/MPC5606E_2N10D.pdf /docs/en/errata/MPC5606E_2N10D.pdf Errata N 155452329886410597 2022-12-07 pdf N en Jul 31, 2014 155452329886410597 Errata N N MPC5606E_2N10D, Mask Set Errata for Mask 2N10D – Errata 35 Rev. 31 OCT 2012 English Mask Set Errata for Mask 1N10D 1354161982638729165603 PSP 142.0 KB None None documents None 1354161982638729165603 /docs/en/errata/MPC5604E_errata_1N10D.pdf 141992 /docs/en/errata/MPC5604E_errata_1N10D.pdf MPC5604E_ERRATA_1N10D documents N N 2016-11-09 Mask Set Errata for Mask 1N10D /docs/en/errata/MPC5604E_errata_1N10D.pdf /docs/en/errata/MPC5604E_errata_1N10D.pdf Errata N 155452329886410597 2023-04-18 pdf N en Nov 28, 2012 155452329886410597 Errata Y N Mask Set Errata for Mask 1N10D 36 Rev 02 Jan 2012 English Mask Set Errata for Mask 0N10D 1325504717460703303886 PSP 132.1 KB None None documents None 1325504717460703303886 /docs/en/errata/MPC5604E_0N10D.pdf 132086 /docs/en/errata/MPC5604E_0N10D.pdf MPC5604E_0N10D documents N N 2012-01-02 Mask Set Errata for Mask 0N10D /docs/en/errata/MPC5604E_0N10D.pdf /docs/en/errata/MPC5604E_0N10D.pdf Errata N 155452329886410597 2022-12-07 pdf N en Jan 2, 2012 155452329886410597 Errata Y N Mask Set Errata for Mask 0N10D ファクト・シート Fact Sheet 1 37 1 English Engineered for prototyping, evaluation, and development of Body & Chassis, Powertrain, in-vehicle Networking, Advanced Driver Assistance Systems (ADAS), Functional Safety and automotive security applications. 1476478892330718459990 PSP 1.2 MB None None documents None 1476478892330718459990 /docs/en/fact-sheet/AUTOMCUDEVKITFS.pdf 1205970 /docs/en/fact-sheet/AUTOMCUDEVKITFS.pdf AUTOMCUDEVKITFS documents N N 2016-11-09 NXP Automotive Development Platforms – Fact Sheet /docs/en/fact-sheet/AUTOMCUDEVKITFS.pdf /docs/en/fact-sheet/AUTOMCUDEVKITFS.pdf Fact Sheet N 736675474163315314 2022-12-07 en Apr 19, 2022 736675474163315314 Fact Sheet Y N NXP Automotive Development Platforms – Fact Sheet 1 Japanese ボディ、シャーシ、パワートレイン、車載ネットワーク、先進運転者支援システム (ADAS)、機能安全、車載セキュリティといった各アプリケーションのプロトタイピング、評価、開発を目的に設計されています。 1476478892330718459990ja PSP 1.2 MB None None documents None 1476478892330718459990 /docs/ja/fact-sheet/AUTOMCUDEVKITFS.pdf 1205970 /docs/ja/fact-sheet/AUTOMCUDEVKITFS.pdf AUTOMCUDEVKITFS documents N N 2016-11-09 NXP Automotive Development Platforms – Fact Sheet /docs/ja/fact-sheet/AUTOMCUDEVKITFS.pdf /docs/ja/fact-sheet/AUTOMCUDEVKITFS.pdf Fact Sheet N 736675474163315314 2022-12-07 pdf N ja Dec 1, 2023 736675474163315314 Fact Sheet Y N NXP自動車向け開発プラットフォーム – ファクト・シート 製品概要 Product Brief 2 38 2 English MPC5606EPB: The MPC5606E microcontroller is a gateway system designed to move data from different sources via Ethernet to a receiving system and vice versa. This device is targeted at the chassis and safety market segment visual-based driver assistance, especially the CMOS Vision Sensor Gateway, Radar Sensor Gateway, and Infotainment Network Gateway. 1408541906261695817823 PSP 575.0 KB None None documents None 1408541906261695817823 /docs/en/product-brief/MPC5606EPB.pdf 575048 /docs/en/product-brief/MPC5606EPB.pdf MPC5606EPB documents N N 2014-08-20 MPC5606EPB: MPC5606E Microcontroller Product Brief - Product Brief /docs/en/product-brief/MPC5606EPB.pdf /docs/en/product-brief/MPC5606EPB.pdf Product Brief N 899114358132306053 2023-06-19 pdf N en Aug 19, 2014 899114358132306053 Product Brief Y N MPC5606EPB: MPC5606E Microcontroller Product Brief - Product Brief 39 2 English MPC5604E Product Brief provides the features of MPC5604E microcontroller, which is a gateway system designed to move data from different sources via Ethernet to a receiving system and vice versa. 1308041731624691396066 PSP 427.1 KB None None documents None 1308041731624691396066 /docs/en/product-brief/MPC5604EPB.pdf 427132 /docs/en/product-brief/MPC5604EPB.pdf MPC5604EPB documents N N 2011-06-14 MPC5604E Microcontroller Product Brief /docs/en/product-brief/MPC5604EPB.pdf /docs/en/product-brief/MPC5604EPB.pdf Product Brief N 899114358132306053 2023-06-19 pdf N en Oct 31, 2011 899114358132306053 Product Brief Y N MPC5604E Microcontroller Product Brief false 0 MPC560xE downloads ja true 1 Y PSP Y Y アプリケーション・ノート 16 /docs/en/application-note/AN13461.pdf 2022-01-04 1641302649210707506203 PSP 8 Nov 30, 2021 Application Note Reviewing the troubleshoot microcontroller when there is a malfunction module. None /docs/en/application-note/AN13461.pdf English documents 302971 None 645036621402383989 2022-12-07 N /docs/en/application-note/AN13461.pdf AN13461: NXP Microcontroller Troubleshooting Checklist - Application Note /docs/en/application-note/AN13461.pdf documents 645036621402383989 Application Note N en None Y pdf 0 N N AN13461: NXP Microcontroller Troubleshooting Checklist - Application Note 303.0 KB AN13461 N 1641302649210707506203 /docs/en/application-note/AN12080.pdf 2017-11-28 1511852813679719749243 PSP 9 Nov 27, 2017 Application Note Guiding on how to initialize the Clock Monitor Unit (CMU) on MPC56xx and MPC57xx microcontrollers. The majority of the MPC56xx and MPC57xx parts have more than one CMU unit. The device has a CMU_0 capable of measuring the IRCOSC, XOSC monitoring, and monitoring one of the other system clocks. The device then contains other CMU_n blocks that are capable of monitoring other important system clocks. None /docs/en/application-note/AN12080.pdf English documents 196599 None 645036621402383989 2022-12-07 N /docs/en/application-note/AN12080.pdf AN12080: The Clock Monitor Unit (CMU) – Application Note /docs/en/application-note/AN12080.pdf documents 645036621402383989 Application Note N en None Y pdf 0 N N AN12080: The Clock Monitor Unit (CMU) – Application Note 196.6 KB AN12080 N 1511852813679719749243 /docs/en/application-note/AN11960.pdf 2017-05-03 1493874951081708875046 PSP 10 May 3, 2017 Application Note Describing the proper method to initialize and change the frequency of the Frequency Modulated Phase Lock Loop (FMPLL) module for the MPC564xA and MPC563xM families of devices. The FMPLL allows the users to generate high-speed system clocks from a crystal oscillator or an external clock generator and supports programmable frequency modulation (FM) of the system clock. None /docs/en/application-note/AN11960.pdf English documents 178663 None 645036621402383989 2022-12-07 N /docs/en/application-note/AN11960.pdf AN11960: MPC564xA/MPC563xM FMPLL Initialization – Application Note /docs/en/application-note/AN11960.pdf documents 645036621402383989 Application Note N en None Y pdf 0 N N AN11960: MPC564xA/MPC563xM FMPLL Initialization – Application Note 178.7 KB AN11960 N 1493874951081708875046 /docs/en/application-note/AN4868.pdf 2017-03-03 1390573644054723435374 PSP 11 Mar 2, 2017 Application Note Describing the basic principles behind using MPC5xxx flash memory for EEPROM emulation, and provides some insight on the functionality of NXP EEPROM emulation drivers. Although MPC55xx, MPC56xx, and MPC57xx MCUs do not include EEPROM, the functionality of this memory type can be emulated with the flash memory that is available. None /docs/en/application-note/AN4868.pdf English documents 498534 None 645036621402383989 2022-12-07 N /docs/en/application-note/AN4868.pdf AN4868: EEPROM Emulation with MPC55xx, MPC56xx, and MPC57xx Microcontrollers – Application Note /docs/en/application-note/AN4868.pdf documents 645036621402383989 Application Note N en None Y pdf 2 N N AN4868: EEPROM Emulation with MPC55xx, MPC56xx, and MPC57xx Microcontrollers – Application Note 498.5 KB AN4868 N 1390573644054723435374 /docs/en/application-note/AN5200.pdf 2021-07-21 1443422519227696132934 PSP 12 Dec 10, 2015 Application Note Outlining how Error-Correcting Codes (ECC) protection is implemented with MPC55xx and MPC56xx devices and understand particular MCU’s ECC event response. Also offering some software examples for illustration of mentioned behavior. None /docs/en/application-note/AN5200.pdf English documents 928642 None 645036621402383989 2022-12-07 N /docs/en/application-note/AN5200.pdf AN5200: Error-Correcting Codes Implemented on MPC55xx and MPC56xx – Application Note /docs/en/application-note/AN5200.pdf documents 645036621402383989 Application Note N en None Y pdf 1 N N AN5200: Error-Correcting Codes Implemented on MPC55xx and MPC56xx – Application Note 928.6 KB AN5200 N 1443422519227696132934 /docs/en/application-note/AN5100.pdf 2015-06-09 1433918705754705848114 PSP 13 Jun 9, 2015 Application Note AN5100: This document provides information about designing automotive board with MPC5606E. It details the key design consideration, the PCB layout and components selection. None /docs/en/application-note/AN5100.pdf English documents 1288074 None 645036621402383989 2022-12-07 N /docs/en/application-note/AN5100.pdf AN5100, MPC5606E: Design for Performance and Electromagnetic Compatibility – Application notes /docs/en/application-note/AN5100.pdf documents 645036621402383989 Application Note N en None N pdf 0 N N AN5100, MPC5606E: Design for Performance and Electromagnetic Compatibility – Application notes 1.3 MB AN5100 N 1433918705754705848114 /docs/en/application-note/AN4805.pdf 2021-07-21 1378914456666698383839 PSP 14 Jan 12, 2014 Application Note Presenting simple semaphore routines (with C code, followed by a detailed explanation of its functionality) that lock, unlock, and reset semaphore gates (flags) on MCP56xx and MPC57xx MCUs. These routines are non-blocking and reentrant functions suitable for multi-core application usage. None /docs/en/application-note/AN4805.pdf English documents 326038 None 645036621402383989 2022-12-07 N /docs/en/application-note/AN4805.pdf AN4805: A Practical Approach to Hardware Semaphores – Application Note /docs/en/application-note/AN4805.pdf documents 645036621402383989 Application Note N en None Y pdf 2 N N AN4805: A Practical Approach to Hardware Semaphores – Application Note 326.0 KB AN4805 N 1378914456666698383839 /docs/en/application-note/AN4756.pdf 2021-07-21 1382000248406719941156 PSP 15 Oct 16, 2013 Application Note Guiding how to configure the eTPU2 for T2/T4 Channel Timing. The Enhanced Time Processing Unit (eTPU) is a programmable I/O controller with its core and memory system, allowing it to perform complex timing and I/O management independently of the CPU. None /docs/en/application-note/AN4756.pdf English documents 226756 None 645036621402383989 2022-12-07 N /docs/en/application-note/AN4756.pdf AN4756: eTPU2 Time Base Running at Full Speed – Application Note /docs/en/application-note/AN4756.pdf documents 645036621402383989 Application Note N en None Y pdf 0 N N AN4756: eTPU2 Time Base Running at Full Speed – Application Note 226.8 KB AN4756 N 1382000248406719941156 /docs/en/application-note/AN4674.pdf 2021-07-21 1360821858350706869722 PSP 16 Jun 30, 2013 Application Note Providing instructions for creating an application program that is capable of uploading the application program to the SoC via the Boot Assist Module (BAM) Enhanced Serial Communication Interface (ESCI) and the Controller Area Network interface (CAN) interface, in either fixed baud rate mode or automatic baud rate detection mode. None /docs/en/application-note/AN4674.pdf English documents 891044 None 645036621402383989 2022-12-07 N /docs/en/application-note/AN4674.pdf AN4674: MPC5xxx Boot Assist Module Application – Application Note /docs/en/application-note/AN4674.pdf documents 645036621402383989 Application Note N en None Y pdf 1 N N AN4674: MPC5xxx Boot Assist Module Application – Application Note 891.0 KB AN4674 N 1360821858350706869722 /secured/assets/documents/en/application-note/AN4752.pdf 2016-10-31 1370013855832696188368 PSP 17 May 31, 2013 Application Note Explaining how to add the FreeMASTER serial driver software to the embedded application and configure it. The FreeMASTER serial driver is a piece of code that enables an embedded application to communicate with the FreeMASTER PC application. Registration without Disclaimer /secured/assets/documents/en/application-note/AN4752.pdf English documents 2220944 None 645036621402383989 2024-07-15 Y /webapp/Download?colCode=AN4752&lang_cd=ja AN4752: FreeMASTER Usage, Serial Driver Implementation – Application Note /secured/assets/documents/en/application-note/AN4752.pdf documents 645036621402383989 Application Note N en Extended Y pdf 0 Y N AN4752: FreeMASTER Usage, Serial Driver Implementation – Application Note 2.2 MB AN4752 N 1370013855832696188368 /docs/en/application-note/AN4753.pdf 2016-10-31 1369937932059742568603 PSP 18 May 30, 2013 Application Note Presenting the use of the Rational ClearCase version control system in CodeWarrior 10.3. It lists the files needed to maintain the project and describes how to install, set up, use, and uninstall the ClearCase plugin in CodeWarrior 10.3. The ClearCase plugin enables you to check files in and out directly from within CodeWarrior, making the work more effective. None /docs/en/application-note/AN4753.pdf English documents 477314 None 645036621402383989 2024-07-15 N /docs/en/application-note/AN4753.pdf AN4753: Rational ClearCase Use in CodeWarrior 10.3 – Application Note /docs/en/application-note/AN4753.pdf documents 645036621402383989 Application Note N en None Y pdf 0 N N AN4753: Rational ClearCase Use in CodeWarrior 10.3 – Application Note 477.3 KB AN4753 N 1369937932059742568603 /docs/en/application-note/AN4648.pdf 2021-07-21 1357316370579707941955 PSP 19 Mar 21, 2013 Application Note Describing a method for decoding the length of VLE instructions is used to increment the returning address of the exception correctly. None /docs/en/application-note/AN4648.pdf English documents 258179 None 645036621402383989 2022-12-07 N /docs/en/application-note/AN4648.pdf AN4648: VLE 16-bit and 32-bit Instruction Length Decode Algorithm – Application Note /docs/en/application-note/AN4648.pdf documents 645036621402383989 Application Note N en None Y pdf 1 N N AN4648: VLE 16-bit and 32-bit Instruction Length Decode Algorithm – Application Note 258.2 KB AN4648 N 1357316370579707941955 /docs/en/application-note/AN4486.pdf 2021-07-21 1331272174444711826479 PSP 20 Mar 8, 2012 Application Note Showing how the MPC5604E SAI can be easily configured for any audio converter. Connecting audio devices to the MPC5604E is an easy task for the MPC5604E Serial Audio Interface (SAI). None /docs/en/application-note/AN4486.pdf English documents 682083 None 645036621402383989 2022-12-07 N /docs/en/application-note/AN4486.pdf AN4486: MPC5604E Serial Audio Interface – Application Note /docs/en/application-note/AN4486.pdf documents 645036621402383989 Application Note N en None Y pdf 0 N N AN4486: MPC5604E Serial Audio Interface – Application Note 682.1 KB AN4486 N 1331272174444711826479 /docs/en/application-note/AN4433.pdf 2021-07-21 1326135258624733883664 PSP 21 Jan 9, 2012 Application Note Describing possible hardware considerations for developing hardware design solutions. It covers topics such as clock generation, decoupling, and voltage regulator, and power considerations. None /docs/en/application-note/AN4433.pdf English documents 910067 None 645036621402383989 2022-12-07 N /docs/en/application-note/AN4433.pdf AN4433: MPC5604E Hardware Design Guide – Application Note /docs/en/application-note/AN4433.pdf documents 645036621402383989 Application Note N en None Y pdf 0 N N AN4433: MPC5604E Hardware Design Guide – Application Note 910.1 KB AN4433 N 1326135258624733883664 /docs/en/application-note/AN4365.pdf 2021-07-21 1316629672453740598962 PSP 22 Sep 21, 2011 Application Note Showing how to develop a flash memory programming tool for the MPC56xx family of devices. Giving some details about the JTAG communication protocol, OnCE module, or the Nexus R/W access block. None /docs/en/application-note/AN4365.pdf English documents 1527214 None 645036621402383989 2022-12-07 N /docs/en/application-note/AN4365.pdf AN4365: MPC56xx Flash Programming Through Nexus/JTAG – Application Note /docs/en/application-note/AN4365.pdf documents 645036621402383989 Application Note N en None Y pdf 0 N N AN4365: MPC56xx Flash Programming Through Nexus/JTAG – Application Note 1.5 MB AN4365 N 1316629672453740598962 /docs/en/application-note/AN4514.pdf 2021-07-21 1334140358906726190760 PSP 1 May 6, 2012 Application Note アプリケーション・ノート Explaining how to connect a video device to the MPC5604E MCU and configure the MPC5604E Video Encoder Wrapper correctly to get MJPEG video stream from your YUV422 video data. None /docs/en/application-note/AN4514.pdf English 407986 None Application Note 2022-12-07 N /docs/en/application-note/AN4514.pdf AN4514: MPC5604E Video Encoder Wrapper – Application Note /docs/en/application-note/AN4514.pdf documents 645036621402383989 Application Note N Y en None Y t789 pdf 1 N N AN4514: MPC5604E Video Encoder Wrapper – Application Note 408.0 KB AN4514 N 1334140358906726190760 アプリケーション・ノート・ソフトウェア 1 /docs/en/application-note-software/AN12080SW.zip 2017-11-24 1511782984892715412544 PSP 25 Nov 26, 2017 Application Note Software AN12080SW, A part's clocks are critical to its safe operation. They need to be accurate and correctly programmed and if there is any variation in their frequency then the application should be notified. None /docs/en/application-note-software/AN12080SW.zip English documents 251963 None 789425793691620447 2022-12-07 N /docs/en/application-note-software/AN12080SW.zip Software for AN12080 /docs/en/application-note-software/AN12080SW.zip documents 789425793691620447 Application Note Software N en None Y zip 0 N N Software for AN12080 252.0 KB AN12080SW N 1511782984892715412544 エラッタ 5 /docs/en/errata/MPC5604E_2N10D.pdf 2014-11-11 1415696681909706249903 PSP 32 Nov 10, 2014 Errata MPC5604E_2N10D, This report applies to mask 2N10D for MPC5604E None /docs/en/errata/MPC5604E_2N10D.pdf English documents 95178 None 155452329886410597 2022-12-07 N /docs/en/errata/MPC5604E_2N10D.pdf MPC5604E_2N10D, Mask Set Errata for Mask 2N10D /docs/en/errata/MPC5604E_2N10D.pdf documents 155452329886410597 Errata N en None Y pdf 10 NOV 2014 N N MPC5604E_2N10D, Mask Set Errata for Mask 2N10D 95.2 KB MPC5604E_2N10D N 1415696681909706249903 /docs/en/errata/MPC5604E_1N10D.pdf 2014-11-11 1415696211817714495518 PSP 33 Nov 10, 2014 Errata MPC5604E_1N10D: This report applies to mask 1N10D for MPC5604E None /docs/en/errata/MPC5604E_1N10D.pdf English documents 95721 None 155452329886410597 2022-12-07 N /docs/en/errata/MPC5604E_1N10D.pdf MPC5604E_1N10D, Mask Set Errata for Mask 1N10D /docs/en/errata/MPC5604E_1N10D.pdf documents 155452329886410597 Errata N en None Y pdf 10 NOV 2014 N N MPC5604E_1N10D, Mask Set Errata for Mask 1N10D 95.7 KB MPC5604E_1N10D N 1415696211817714495518 /docs/en/errata/MPC5606E_2N10D.pdf 2014-08-01 1406877130880694181806 PSP 34 Jul 31, 2014 Errata MPC5606E_2N10D: This errata presents information about Mask Set Errata for Mask 2N10D. None /docs/en/errata/MPC5606E_2N10D.pdf English documents 99183 None 155452329886410597 2022-12-07 N /docs/en/errata/MPC5606E_2N10D.pdf MPC5606E_2N10D, Mask Set Errata for Mask 2N10D – Errata /docs/en/errata/MPC5606E_2N10D.pdf documents 155452329886410597 Errata N en None N pdf Rev 28 JUL 2014 N N MPC5606E_2N10D, Mask Set Errata for Mask 2N10D – Errata 99.2 KB MPC5606E_2N10D N 1406877130880694181806 /docs/en/errata/MPC5604E_errata_1N10D.pdf 2016-11-09 1354161982638729165603 PSP 35 Nov 28, 2012 Errata Mask Set Errata for Mask 1N10D None /docs/en/errata/MPC5604E_errata_1N10D.pdf English documents 141992 None 155452329886410597 2023-04-18 N /docs/en/errata/MPC5604E_errata_1N10D.pdf Mask Set Errata for Mask 1N10D /docs/en/errata/MPC5604E_errata_1N10D.pdf documents 155452329886410597 Errata N en None Y pdf Rev. 31 OCT 2012 N N Mask Set Errata for Mask 1N10D 142.0 KB MPC5604E_ERRATA_1N10D N 1354161982638729165603 /docs/en/errata/MPC5604E_0N10D.pdf 2012-01-02 1325504717460703303886 PSP 36 Jan 2, 2012 Errata Mask Set Errata for Mask 0N10D None /docs/en/errata/MPC5604E_0N10D.pdf English documents 132086 None 155452329886410597 2022-12-07 N /docs/en/errata/MPC5604E_0N10D.pdf Mask Set Errata for Mask 0N10D /docs/en/errata/MPC5604E_0N10D.pdf documents 155452329886410597 Errata N en None Y pdf Rev 02 Jan 2012 N N Mask Set Errata for Mask 0N10D 132.1 KB MPC5604E_0N10D N 1325504717460703303886 エンジニアリング・ブリテン 6 /docs/en/engineering-bulletin/EB00877.pdf 2019-02-14 1550136400774719898938 PSP 26 Feb 13, 2019 Technical Notes EB00877, This engineering bulletin provides guidance on programming Priority(PRI) bits of the Interrupt Controller Current Priority Register(INTC_CPRn[PRI]) to ensure coherency of shared resource between Interrupt Services Routines(ISRs) for the MPC56xx and MPC57xx family of devices. None /docs/en/engineering-bulletin/EB00877.pdf English documents 131838 None 389245547230346745 2022-12-07 N /docs/en/engineering-bulletin/EB00877.pdf EB00877, Programming Priority Bits in the Interrupt Controller Current Priority Register for MPC56xx and MPC57xx Families /docs/en/engineering-bulletin/EB00877.pdf documents 389245547230346745 Technical Notes N en None Y pdf 0 N N EB00877, Programming Priority Bits in the Interrupt Controller Current Priority Register for MPC56xx and MPC57xx Families 131.8 KB EB00877 N 1550136400774719898938 /docs/en/engineering-bulletin/EB00855.pdf 2017-05-25 1495699633841705738852 PSP 27 May 24, 2017 Technical Notes EB00855, This engineering bulletin provides guidance on programming reserved register bits for the MPC55xx, MPC56xx, and MPC57xx families of devices. None /docs/en/engineering-bulletin/EB00855.pdf English documents 162731 None 389245547230346745 2022-12-07 N /docs/en/engineering-bulletin/EB00855.pdf EB00855, Programming Reserved Register Bits for MPC55xx, MPC56xx, and MPC57xx Families /docs/en/engineering-bulletin/EB00855.pdf documents 389245547230346745 Technical Notes N en None pdf 0 N N EB00855, Programming Reserved Register Bits for MPC55xx, MPC56xx, and MPC57xx Families 162.7 KB EB00855 N 1495699633841705738852 /docs/en/engineering-bulletin/EB795.pdf 2013-09-01 1378092305734717489368 PSP 28 Aug 30, 2013 Technical Notes EB795:This document aims to describe Errata 7026 which affect the MPC564xS devices and how to safely handle it. None /docs/en/engineering-bulletin/EB795.pdf English documents 409249 None 389245547230346745 2022-12-07 N /docs/en/engineering-bulletin/EB795.pdf EB795, Working around ERR7026 according to application needs - Engineering Bulletin /docs/en/engineering-bulletin/EB795.pdf documents 389245547230346745 Technical Notes N en None Y pdf 0 N N EB795, Working around ERR7026 according to application needs - Engineering Bulletin 409.2 KB EB795 N 1378092305734717489368 /secured/assets/documents/en/engineering-bulletin/EB793.pdf 2016-10-31 1369851108709706895647 PSP 29 May 28, 2013 Technical Notes EB793: This document, developed in response to customer inquiries, describes Motor Industry Software Reliability Association (MISRA™) compliance in the C Language header files provided by NXP for the automotive market. Registration without Disclaimer /secured/assets/documents/en/engineering-bulletin/EB793.pdf English documents 197012 None 389245547230346745 2024-07-15 Y /webapp/Download?colCode=EB793&lang_cd=ja MISRA Compliance in Freescale Automotive C Language Header Files - Engineering Bulletin /secured/assets/documents/en/engineering-bulletin/EB793.pdf documents 389245547230346745 Technical Notes N en Extended Y pdf 1 Y N MISRA Compliance in Freescale Automotive C Language Header Files - Engineering Bulletin 197.0 KB EB793 N 1369851108709706895647 /docs/en/engineering-bulletin/EVB772.pdf 2012-01-03 1325584485811732432483 PSP 30 Jan 2, 2012 Technical Notes The purpose of this engineering bulletin is to describe how to apply errata 4080 to MPC5604E Evaluation Board. This errata describe issue where device cannot come out of reset till VDD_LV is less than a threshold value. This document is valid for evaluation boards where device with mask 0N10D is installed and board is not marked with a TDA4008 label. None /docs/en/engineering-bulletin/EVB772.pdf English documents 180086 None 389245547230346745 2022-12-07 N /docs/en/engineering-bulletin/EVB772.pdf Applying Errata ID 4080 to MPC5604E Evaluation Board /docs/en/engineering-bulletin/EVB772.pdf documents 389245547230346745 Technical Notes N en None Y pdf 1 N N Applying Errata ID 4080 to MPC5604E Evaluation Board 180.1 KB EB772 N 1325584485811732432483 /docs/en/engineering-bulletin/EB758.pdf 2011-10-14 1318598668663692344265 PSP 31 Oct 10, 2011 Technical Notes This document describes how to use Qorivva header files in the C programming language. It highlights the instructions generated by C compilers and discusses the related consequences for the MCU’s hardware. None /docs/en/engineering-bulletin/EB758.pdf English documents 323744 None 389245547230346745 2022-12-07 N /docs/en/engineering-bulletin/EB758.pdf Using MPC5xxx Header Files In C /docs/en/engineering-bulletin/EB758.pdf documents 389245547230346745 Technical Notes N en None Y pdf 0 N N Using MPC5xxx Header Files In C 323.7 KB EB758 N 1318598668663692344265 データ・シート 2 /docs/en/data-sheet/MPC5604E.pdf 2020-03-02 1308040802351722232495 PSP 2 Mar 2, 2020 Data Sheet データ・シート MPC5604E: This document provides electrical specifications, pin assignments, and package diagrams for the MPC5604E series of microcontroller units (MCUs). None /docs/en/data-sheet/MPC5604E.pdf English 1036307 None Data Sheet 2022-12-07 N /docs/en/data-sheet/MPC5604E.pdf MPC5604E Microcontroller Data Sheet /docs/en/data-sheet/MPC5604E.pdf documents 980000996212993340 Data Sheet N Y en None Y t520 pdf 6 N N MPC5604E Microcontroller Data Sheet 1.0 MB MPC5604E N 1308040802351722232495 /docs/en/data-sheet/MPC5606E.pdf 2020-03-02 1408542755635715750496 PSP 4 Sep 21, 2020 Data Sheet データ・シート MPC5606E: This document provides electrical specifications, pin assignments, and package diagrams for the MPC5606E series of microcontroller units (MCUs). This document describes the features of the family and options available within the family members, and highlights important electrical and physical characteristics of the devices.

 None /docs/en/data-sheet/MPC5606E.pdf English 1462493 None Data Sheet 2022-12-07 N /docs/en/data-sheet/MPC5606E.pdf MPC5606E, MPC5606E Microcontroller Data Sheet - Data Sheet /docs/en/data-sheet/MPC5606E.pdf documents 980000996212993340 Data Sheet N Y en None Y t520 pdf 4 N N MPC5606E, MPC5606E Microcontroller Data Sheet - Data Sheet 1.5 MB SPC5606EEF2VMC,SPC5606EF2VMC MPC5606E N 1408542755635715750496 ファクト・シート 2 /docs/ja/fact-sheet/AUTOMCUDEVKITFS.pdf 2016-11-09 1476478892330718459990ja PSP 37 Dec 1, 2023 Fact Sheet ボディ、シャーシ、パワートレイン、車載ネットワーク、先進運転者支援システム (ADAS)、機能安全、車載セキュリティといった各アプリケーションのプロトタイピング、評価、開発を目的に設計されています。 None /docs/ja/fact-sheet/AUTOMCUDEVKITFS.pdf Japanese documents 1205970 None 736675474163315314 2022-12-07 N /docs/ja/fact-sheet/AUTOMCUDEVKITFS.pdf NXP自動車向け開発プラットフォーム – ファクト・シート /docs/ja/fact-sheet/AUTOMCUDEVKITFS.pdf documents 736675474163315314 Fact Sheet N ja None Y pdf 1 N N NXP Automotive Development Platforms – Fact Sheet 1.2 MB AUTOMCUDEVKITFS N 1476478892330718459990 /docs/en/fact-sheet/MPC5606EFS.pdf 2016-10-31 1395701531068705748739 PSP 3 Mar 24, 2014 Fact Sheet ファクト・シート The Qorivva MPC5606E MCU family is built on Power Architecture® technology designed for automotive video compression and transmission over Ethernet and ideal for camera-based ADAS surround view and park assist applications. None /docs/en/fact-sheet/MPC5606EFS.pdf English 448130 None Fact Sheet 2022-12-07 N /docs/en/fact-sheet/MPC5606EFS.pdf Freescale MPC5606E MCU - Fact Sheet /docs/en/fact-sheet/MPC5606EFS.pdf documents 736675474163315314 Fact Sheet N Y en None Y t523 pdf 0 N N Freescale MPC5606E MCU - Fact Sheet 448.1 KB MPC5606EFS N 1395701531068705748739 ユーザ・ガイド 2 /docs/en/user-guide/MPC5606EBUG.pdf 2014-04-04 1395956692128704082902 PSP 23 Apr 8, 2014 User Guide MPC5606EBUG: This document evaluates MPC5606E Evaluation Board (EVB) that is based on the e200z0 Power Architecture core. The MPC5606E 121-pin MAPBGA is assembled on this board to allow the evaluation of the full functionality of this part.?? None /docs/en/user-guide/MPC5606EBUG.pdf English documents 492133 None 132339537837198660 2023-06-18 N /docs/en/user-guide/MPC5606EBUG.pdf MPC5606EBUG, MPC5606E Board User Guide - User Guide /docs/en/user-guide/MPC5606EBUG.pdf documents 132339537837198660 User Guide N en None Y pdf 2 N N MPC5606EBUG, MPC5606E Board User Guide - User Guide 492.1 KB MPC5606EBUG N 1395956692128704082902 /docs/en/user-guide/MPC5604EEVB64UM.pdf 2011-10-13 1318500737841712455929 PSP 24 Oct 12, 2011 User Guide The MPC5604EEVB64 Evaluation Board (EVB) is
based on the e200z0 Power Architecture®. This board is shipped with the PPC5604EEMLH 64-pin LQFP MCU populated to allow the evaluation of the full functionality of this part. None /docs/en/user-guide/MPC5604EEVB64UM.pdf English documents 1850697 None 132339537837198660 2023-06-18 N /docs/en/user-guide/MPC5604EEVB64UM.pdf MPC5604EEVB64 Evaluation board User Manual /docs/en/user-guide/MPC5604EEVB64UM.pdf documents 132339537837198660 User Guide N en None Y pdf 0 N N MPC5604EEVB64 Evaluation board User Manual 1.9 MB MPC5604EEVB64UM N 1318500737841712455929 リファレンス・マニュアル 3 /secured/assets/documents/en/reference-manual/MPC5606ERM.pdf 2016-10-31 1408540963296699412730 PSP 6 Aug 20, 2014 Reference Manual MPC5606ERM: This reference manual describes the MPC5604E processor for software and hardware developers. The MPC5606E microcontroller is a gateway system designed to move data from different sources. Registration without Disclaimer /secured/assets/documents/en/reference-manual/MPC5606ERM.pdf English documents 16060753 None 500633505221135046 2022-12-07 Y /webapp/Download?colCode=MPC5606ERM&lang_cd=ja MPC5606ERM: MPC5606E Microcontroller Reference Manual /secured/assets/documents/en/reference-manual/MPC5606ERM.pdf documents 500633505221135046 Reference Manual N en Extended Y pdf 2 Y N MPC5606ERM: MPC5606E Microcontroller Reference Manual 16.1 MB MPC5606ERM N 1408540963296699412730 /secured/assets/documents/en/reference-manual/SPE2PIM.pdf 2016-10-31 1312437745440709015400 PSP 7 Aug 3, 2013 Reference Manual SPE2PIM - Help programmers provide software that is compatible across the family of processors that use the enhanced signal processing (SPE2) and embedded floating-point version-2 (EFP2) auxiliary processing unit (APU) extension. Registration without Disclaimer /secured/assets/documents/en/reference-manual/SPE2PIM.pdf English documents 24767945 None 500633505221135046 2022-12-07 Y /webapp/Download?colCode=SPE2PIM&lang_cd=ja SPE2PIM - Enhanced Signal Processing Extension and Embedded Floating-Point Version 2 Auxiliary Processing Units Programming Interface Manual /secured/assets/documents/en/reference-manual/SPE2PIM.pdf documents 500633505221135046 Reference Manual N en Extended Y pdf 1.0-2 Y N SPE2PIM - Enhanced Signal Processing Extension and Embedded Floating-Point Version 2 Auxiliary Processing Units Programming Interface Manual 24.8 MB SPE2PIM N 1312437745440709015400 /secured/assets/documents/en/reference-manual/MPC5604ERM.pdf 2016-10-31 1321009215715725642934 PSP 5 Jul 30, 2015 Reference Manual リファレンス・マニュアル This reference manual describes the MPC5604E processor for software and hardware developers.
 Registration without Disclaimer /secured/assets/documents/en/reference-manual/MPC5604ERM.pdf English 16105718 None Reference Manual 2023-06-18 Y /webapp/Download?colCode=MPC5604ERM&docLang=en MPC5604E Microcontroller Reference Manual /secured/assets/documents/en/reference-manual/MPC5604ERM.pdf documents 500633505221135046 Reference Manual N Y en Extended Y t877 pdf 5 Y N MPC5604E Microcontroller Reference Manual 16.1 MB MPC5604ERM N 1321009215715725642934 製品概要 2 /docs/en/product-brief/MPC5606EPB.pdf 2014-08-20 1408541906261695817823 PSP 38 Aug 19, 2014 Product Brief MPC5606EPB: The MPC5606E microcontroller is a gateway system designed to move data from different sources via Ethernet to a receiving system and vice versa. This device is targeted at the chassis and safety market segment visual-based driver assistance, especially the CMOS Vision Sensor Gateway, Radar Sensor Gateway, and Infotainment Network Gateway. None /docs/en/product-brief/MPC5606EPB.pdf English documents 575048 None 899114358132306053 2023-06-19 N /docs/en/product-brief/MPC5606EPB.pdf MPC5606EPB: MPC5606E Microcontroller Product Brief - Product Brief /docs/en/product-brief/MPC5606EPB.pdf documents 899114358132306053 Product Brief N en None Y pdf 2 N N MPC5606EPB: MPC5606E Microcontroller Product Brief - Product Brief 575.0 KB MPC5606EPB N 1408541906261695817823 /docs/en/product-brief/MPC5604EPB.pdf 2011-06-14 1308041731624691396066 PSP 39 Oct 31, 2011 Product Brief MPC5604E Product Brief provides the features of MPC5604E microcontroller, which is a gateway system designed to move data from different sources via Ethernet to a receiving system and vice versa. None /docs/en/product-brief/MPC5604EPB.pdf English documents 427132 None 899114358132306053 2023-06-19 N /docs/en/product-brief/MPC5604EPB.pdf MPC5604E Microcontroller Product Brief /docs/en/product-brief/MPC5604EPB.pdf documents 899114358132306053 Product Brief N en None Y pdf 2 N N MPC5604E Microcontroller Product Brief 427.1 KB MPC5604EPB N 1308041731624691396066 true Y Products
