Kinetis KV1x Family Tower System Module

TWR-KV11Z75M アクティブ

画像にカーソルを合わせると拡大表示されます。

The TWR-KV11Z75M is a development tool for the Kinetis V series KV1x 64 KB and 128 KB MCU family built on the ARM® Cortex®-M0+ processor.

As is standard with all Tower System modules, the TWR-KV11Z75M MCU module can be used with a variety of existing peripheral modules, such as TWR-MC-LV3PH for motor control rapid rapid prototyping. The TWR-KV11Z75M is supported by a range of Freescale and third-party development software. Torque your designs and speed your time to market with TWR-KV11Z75M.

製品詳細

対応製品

プロセッサ＆マイクロコントローラ

KVシリーズArm Cortex-M4/M0+/M7

  • KV1x: Kinetis® KV1x-75 MHz,  Entry-Level 3ph FOC / Sensorless Motor Control MCUs based on Arm® Cortex®-M0+
