NXP collaborates with select partners to offer multiple solutions for developing embedded GUIs of all levels of complexity. The following solutions are provided via MCUXpresso SDK, Open-CMSIS-packs or custom release of each partner. These come with ready-to-use software examples to help you complete an in-depth evaluation and get started with your design.
Graphical User Interfaces for NXP Microcontrollers
Consumer, industrial and medical goods are becoming smarter, and a growing number are boasting complex, smartphone-like GUIs. NXP makes developing optimized embedded GUIs easy with a broad and scalable portfolio, integrated display controllers and graphics accelerators and multiple graphics libraries and tools that support its broad range of microcontrollers. Evaluation versions of Enabling Software Technologies Partners’ solutions are available in the MCUXpresso SDK released via Open-CMSIS-Packs or directly inside SDK or via custom package including application examples, enabling rapid evaluation and easy transition to full development.
ソフトウェア詳細
Features
General
- Most of graphics middleware is released over Open-CMSIS-Packs
- MCUXpresso SDK includes multiple graphics middleware options
- Fully-functional example applications make evaluating each solution simple
- Several NXP device families are optimized for rich graphics applications with integrated hardware features
対応製品
-
プロセッサ＆マイクロコントローラ
-
Armマイクロコントローラ
-
i.MX RTクロスオーバーMCU
-
Kinetis® K2x USB マイクロコントローラ(MCUs)Arm® Cortex®-M4コアをベース
-
LPC54000シリーズ： Arm® Cortex®-M4コアを搭載した電力効率に優れたマイクロコントローラ(MCU)
-
LPC5500シリーズ：マス・マーケット向けArm® Cortex ®-M33ベース・マイクロコントローラ・シリーズ（40 nm組込みフラッシュ・テクノロジ採用）
-
-
Graphics Ecosystem Libraries and Examples
| Crank | AMETEK | TARA Systems | LVGL | Segger | Altia | The Qt Company | MicroEJ | |
|---|---|---|---|---|---|---|---|
| Partner Solutions | Storyboard | Embedded Wizard | LVGL Open-Source Graphics Library | NXP emWin Libraries | Altia Design | Qt For MCUs | MicroEJ GUI Solutions |
| Partners |
|
|
|
|
|
|
|
| Supported Devices |
i.MX RT500 i.MX RT1040 i.MX RT1050 i.MX RT106x i.MX RT1170 |
K2x, K6x i.MX RT595 i.MX RT685 i.MX RT101x i.MX RT1040 i.MX RT1050 i.MX RT106x i.MX RT117x LPC54S/540xx LPC546xx LPC55Sxx |
K2x, K6x i.MX RT595 i.MX RT685 i.MX RT101x i.MX RT102x i.MX RT1040 i.MX RT1050 i.MX RT106x i.MX RT116x i.MX RT117x LPC54S/540xx LPC546xx LPC55Sxx |
K2x,K6x i.MX RT595 i.MX RT685 i.MX RT101x i.MX RT1050 i.MX RT106x i.MX RT116x i.MX RT117x LPC54S/540xx LPC546xx LPC55Sxx |
i.MX RT1050 i.MX RT106x i.MX RT1160 i.MX RT1170 |
i.MX RT500 i.MX RT1050 i.MX RT106x i.MX RT1170 |
i.MX RT500 i.MX RT1050 LPC546xx |
| Release options | Open-CMSIS-Pack | Open-CMSIS-Pack | Open-CMSIS-Pack MCUXpresso SDK |
MCUXpresso SDK | Custom | Custom | Custom | Webpage | Crank | AMETEK | TARA Systems GmbH | LVGL Kft | SEGGER Microcontroller GmbH | Altia | The Qt Company | MicroEJ |
MCUXpresso SDK Downloads by Development Board
Use the following links to build and download SDK including graphic libraries. SDK Builder helps you to include graphics and libraries examples for other boards also.
ダウンロード
クイック・リファレンス ソフトウェア・タイプ.
1 ダウンロード
-
使用例とクイック・スタート・ソフトウェア
MCUXpresso SDK - SDK Builder
