Ultra-Reliable MPC5777C MCU for Automotive and Industrial Engine Management

MPC5777C アクティブ

The MPC5777C Power Architecture® MCU targets industrial and automotive engine control applications that require advanced performance, timing systems, security, and functional safety capabilities. The family offers a high-performance multicore architecture with industry standard eTPU based timer system. A Flash offering that supports code expansion, a security module, and packaging options are available along with the highest level of functional safety (ASIL D) support.

ブロック図

MPC5777C Block Diagram

MPC5777C Engine Control MCU
図を取得する PDF

Features

General

  • Two independent Power Architecture z7 cores with up to 300 MHz operation
  • Single z7 core in Lockstep with one of the main cores
  • 8M Flash
  • 512kB total SRAM
  • 3 eTPU2 timers with 96 channels
  • eMIOS timer with 32 channels
  • Ethernet 10/100
  • Four Sigma Delta and four eQADC converters
  • Built to support functional safety (ISO 26262/ASIL D)
  • 416 and 516 BGA
  • -40 to 125C Ta Operation
