S12XF Automotive and Industrial Microcontrollers (MCUs)
- このページでは、新規設計を推奨しない製品に関する情報を掲載しています。
Based on Our S12X architecture, the MC9S12XF family gives you a high-performance, cost-effective distributed control solution for satellite nodes on FlexRay™ networks used in body, chassis and safety applications.
Replacing 32-bit controllers for satellite nodes provides a reduction in overall system cost for FlexRay networks.
The S12XF family features four highly integrated MCUs offering a range of memory configurations and NXP®.s performance-boosting XGATE coprocessor.
Package options range from 112-pin low-profile quad flat-pack (LQFP) to the 10 mm x 10 mm 64-pin LQFP—the smallest FlexRay controller available.
製品詳細
ブロック図
Features
-
Key Features
- FlexRay Controller
- XGATE co-processor capable for build virtual peripherials and boost the overall performance
- Flexible programmable hardware emulated EEPROM
- System integrity support with the memory protection unit (MPU) and supervisor/user modes
- This product is included in NXP product longevity program, with assured supply for a minimum of 15 years after launch
-
Other Features
- S12X CPU @ 50 MHz bus speed
- Loop control/full-swing pierce oscillator
- Enhanced interrupt module
- Analog-to-digital Converter ADC 12-bit resolution and 3μs conversion time
- Enhanced capture timer (ECT)
- Periodic interrupt timer (PIT)
- Real-time interrupt (RTI)
- Asynchronous periodic interrupt (API)
- Pulse width modulator (PWM)
- MSCAN module
- Serial peripherial interface (SPI)
- Serial communication interface (SCI)
- Background debug module (BDM) and debugger (xDBG)
- On-chip voltage regulator
購入/パラメータ
|
|
|
|
|
|
|
|---|---|---|---|---|---|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
設計・リソース
ハードウェア
クイック・リファレンス
ボードタイプ.
5 ハードウェア提供
-
評価・開発ボードMC9S12XF512 Evaluation Board注目
-
評価・開発ボードS12XF 2-Node Starter Kit注目
-
アダプタ、ケーブル、ソケットMC9S12XF Adapters
-
エミュレータ、プローブ、プログラマPEmicro Cyclone FX programmer
-
評価・開発ボードFlexRay Daughter Card (FRDC)
ソフトウェア
クイック・リファレンス ソフトウェア・タイプ.
1-5 の 8 ソフトウェア・ファイル
-
BSPとデバイスドライバ
Graphical LCD Driver for MCUs/MPUs注目
-
BSPとデバイスドライバ
LIN2.x and SAE J2602 Stack
-
BSPとデバイスドライバ
Standard Software Driver for 0.18um NVM in S12XE/F
-
ライブラリ
MSCAN driver for S12(X) devices
