Ultra-Reliable S12G General Purpose Automotive and Industrial Microcontrollers

S12G
アクティブ
NXP Doubles Portfolio of MagniV Microcontrollers

動画の上をクリックすると再生されます。

The S12G is an optimized, 16-bit microcontroller product line focused on low cost, high performance and low pin count. The S12G is suited for generic automotive and industrial applications requiring CAN or LIN/SAE J2602 communication.

The S12G delivers all the advantages and efficiencies of a 16-bit MCU while retaining the cost effectiveness, power consumption, EMC and code-size efficiency advantages currently enjoyed by users of our existing 8-bit and 16-bit MCU families.

ブロック図

S12G Microcontroller Block Diagram

S12G Microcontroller Block Diagram
図を取得する PDF

Features

  • S12 CPU core, 25 MHz bus
  • Up to 240 KB on-chip flash with ECC
  • Up to 4 KB EEPROM with ECC
  • Up to 11 KB on-chip SRAM
  • Up to one multi-scalable controller area network (MSCAN) module
    • Supporting CAN protocol 2.0 A/B
  • Up to three serial communication interface (SCI) modules
    • Supporting LIN communications
  • Up to three serial peripheral interface (SPI) modules
  • Precision fixed voltage reference for analog-to-digital conversion (ADC)
  • 1 MHz internal oscillator
  • On-chip voltage regulator for input supply and internal voltages
  • This product is included in NXP® product longevity program, with assured supply for a minimum of 15 years after launch

S12G Family Comparison table

EEPROM Internal RAM Internal Flash Serial Interface Type 16-bit Timers ADC Bits/Channels Package Description
S12GN16 0.5 KB
1 KB
16 KB
SCI
SPI
Timer Channels: 6
Number of Timers: 1
10
LQFP 32 7*7*1.4P0.8
LQFP 48 7*7*1.4P0.5
S12GN32 1 KB
2 KB
32 KB
SCI
SPI
Timer Channels: 6
Number of Timers: 1
10
LQFP 32 7*7*1.4P0.8
QFN-EP 48 7.0SQ*1.0P0.5
LQFP 48 7*7*1.4P0.5
S12G48 1.5 KB
4 KB
48 KB
CAN
SCI
SPI
Timer Channels: 6
Number of Timers: 1
10
LQFP 32 7*7*1.4P0.8
LQFP 64 10*10*1.4P0.5
LQFP 48 7*7*1.4P0.5
S12G64 2 KB
4 KB
64 KB
CAN
SCI
SPI
Timer Channels: 6
Number of Timers: 1
10
LQFP 48 7*7*1.4P0.5
LQFP 64 10*10*1.4P0.5
LQFP 32 7*7*1.4P0.8
S12G96 3 KB
4 KB
8 KB
96 KB
CAN
SCI
SPI
Timer Channels: 8
Number of Timers: 1
10
LQFP 64 10*10*1.4P0.5
LQFP 48 7*7*1.4P0.5
LQFP 100 14*14*1.4P0.5
S12G128 4 KB
8 KB
128 KB
CAN
SCI
SPI
Timer Channels: 8
Number of Timers: 1
10
LQFP 64 10*10*1.4P0.5
LQFP 100 14*14*1.4P0.5
LQFP 48 7*7*1.4P0.5
S12G192 4 KB
12 KB
192 KB
CAN
SCI
SPI
Timer Channels: 8
Number of Timers: 1
10
12
LQFP 64 10*10*1.4P0.5
LQFP 48 7*7*1.4P0.5
LQFP 100 14*14*1.4P0.5
S12G240 4 KB
12 KB
11 KB
240 KB
CAN
SCI
SPI
Timer Channels: 8
Number of Timers: 1
12
10
LQFP 64 10*10*1.4P0.5
LQFP 48 7*7*1.4P0.5
LQFP 100 14*14*1.4P0.5
