POS Terminal
Point of Sale (PoS) terminals are key elements in payment systems for retailers or restaurants in Smart Cities. These battery-powered terminals have small form factors and can integrate functions such as a display, a card reader, a keypad and a printer. Terminals usually include wireless communication to a back-office server or a main stationary ePOS terminal. They also support magnetic, smart and contactless payment cards.
NXP solutions power secure, on-the-go mobile payment terminals, providing end users the ease-of-use of contact and contactless payment. Our security features help the designer to get the necessary PCI PTS PIN entry device (PED) and EMVCo certifications.
アプリケーションの詳細
ブロック図
の推奨製品です。:
POS
ブロックを選択すると、推奨製品が表示されます。.
MCU
- MCX A13x、14x、15x MCU：Arm® Cortex® M33、拡張性の高いデバイス・オプション、低消費電力でインテリジェントなペリフェラルを搭載
- MCX-N94X-N54X: MCX N94x/54x オンチップ・アクセラレータ、インテリジェントなペリフェラル、高度なセキュリティを備えた高集積マルチコアMCU
- K81_150: Kinetis K81-150 MHz HW Cryptographic Co-Processor, Anti-Tamper and QuadSPI Microcontrollers (MCUs) Based on Arm® Cortex®-M4 Core
- i.MX-RT1170: i.MX RT1170：Arm® Cortex®コア搭載1 GHzクロスオーバーMCU
USB Type C Delivery
RTC
Contact Reader
Contactless Reader
- PN5190: 困難なRF環境にも対応する、決済および物理的アクセス制御向けNFCフロントエンド
I2C Expander
Wireless Charging receiver
- MWPR1516: 15 Watt Wireless Charging Receiver ICs
Wi-Fi + Bluetooth
Level Translator
Security (EdgeLock Discrete)
Serial USB Load SW
- NX5P3290UK: USB PD and Type-C Current-Limited Power Switch
LED Driver
- PCA9632: 4-Bit Fm+ I²C-Bus Low-Power LED Driver
Designs
Reference Design
PIN Pad Point of Sale (POS) Solution
The PIN Pad Point of Sale (POS) Solution has been designed to be a PIN Entry Device (PED) in the PCI certification process.
