The LX2162A (also known as “LX2-Lite”) processor squeezes the processing capability of the popular LX2160A device into a package that is nearly one quarter the size. It combines the low power of the 16nm FinFET process technology and sixteen Arm^® Cortex^®-A72 cores with data path acceleration optimized for L2/3 packet processing, security offload and robust traffic management and quality of service.

This advanced processor is suitable for small boards such as network interface cards, COM Express Type 7 modules, OCP3 mezzanine cards and custom daughter cards. It retains LX2160A’s 16 Cortex-A72 cores, 50 Gbit/s security engine and 88 Gbit/s data compression engine. It has 12 SerDes lanes at up to 25 Gbit/s, which can support four 25 Gbit Ethernet and x8 PCIe Gen3 simultaneously, among many other combinations.

For Edge Computing, this processor offers outstanding computing performance with a powerful packet offload and Ethernet controllers. In one device you can have high-end, high-speed communications, with low-speed peripherals such as sensors and the computing power to process and act upon all received information.

Layerscape processors are part of NXP's EdgeVerse™ edge computing platform.

データ・シート

リファレンス・マニュアル

製品詳細

ブロック図

Layerscape LX2162A Block Diagram

図を取得する PDF

Features

16-64-bit Armv8 Cortex-A72 CPU cores, running up to 2.0 GHz
16 MB cache
12 SerDes lanes, operating up to 25 GHz
Up to 12 Ethernet ports
Supported Ethernet speeds include 1, 2.5, 10, 25, 40 and 50 Gbit/s
105 Gbit/s Layer 2 Ethernet switch
Up to 12 PCIe Gen3 lanes, supporting three ports, as wide as x8
50 Gbit/s security accelerator
88 Gbit/s data compression/decompression engine
Package: 23x23mm, 1150 pins
DDR4 72b including ECC, to 2900 MT/s, maximum capacity of 32 GB

比較表

Layerscape LX2162A Family Members

	LX2162A	LX2122A	LX2082A
Cores	16	12	8
L2 cache	8MB	6MB	8MB
SerDes	12 lanes at up to 25 GHz
PCIe^®	3 x Gen3, max width of x8
DDR	DDR4, 2900 MT/s, 32 GB capacity
Platform cache + PEB	10MB
Ethernet	105 Gbit/s L2 switch, supporting combinations of 12 ports of 1, 2.5, 10, 25, 40 and 50 Gbit Ethernet
Security	50 Gbit/s
Data Compression Engine	88 Gbit/s
Package	23 x 23 mm, 1150 pins

購入/パラメータ

パーツ説明を表示	Silicon Rev	ファミリー	状況	開発ツール	製品認証	標準価格	パッケージ端子数	パッケージタイプ	Package Pitch (mm)	コア・タイプ	コア：コア数 - 仕様	動作周波数[最大](MHz)	Typical Power	Cache (KB)	L1 Cache (KB)	L2 Cache (Max) (KB)	SRAM (kB)	対応する外部メモリ	DRAM frequency (max)(MHz)	SPI	QSPI	UART	I²C	USB Controllers	CAN	Ethernet Ports	イーサネット・タイプ	PCIe	PCIe version	SATA	Encryption	Watchdog timer	タイマー	デバッグ & トレース	Ambient Operating Temperature (Min to Max) (℃)	Junction Temperature (Min to Max) (℃)
LX2082RC82029B データ・シート	Rev 2	LX2162 family	アクティブ	LX2160A-RDB-B	5-year Indoor	100 @ US$245.78	1150	FBGA1150	0.65	Arm Cortex-A72	8	2000	20.1	32, 48	32, 48	8192	256	FlexSPI, L2 CACHE, SDRAM DDR4 RDIMM, SDRAM DDR4 UDIMM	2900	3	2	4	8	1	2	12	10G, 1G, 25 Gbit/s, 50 Gbit/s	3	PCIe 3.0	4 x SATA 3.0	Y	Y	2	JTAG	5 to 105	5 to 105
LX2082RE82029B データ・シート	Rev 2	LX2162 family	アクティブ	LX2160A-RDB-B	5-year Indoor	100 @ US$234.07	1150	FBGA1150	0.65	Arm Cortex-A72	8	2000	20.1	32, 48	32, 48	8192	256	FlexSPI, L2 CACHE, SDRAM DDR4 RDIMM, SDRAM DDR4 UDIMM	2900	3	2	4	8	1	2	12	10G, 1G, 25 Gbit/s, 50 Gbit/s	3	PCIe 3.0	4 x SATA 3.0	Y	Y	2	JTAG	5 to 105	5 to 105
LX2082RN82029B データ・シート	Rev 2	LX2162 family	アクティブ	LX2160A-RDB-B	5-year Indoor	100 @ US$234.07	1150	FBGA1150	0.65	Arm Cortex-A72	8	2000	20.1	32, 48	32, 48	8192	256	FlexSPI, L2 CACHE, SDRAM DDR4 RDIMM, SDRAM DDR4 UDIMM	2900	3	2	4	8	1	2	12	10G, 1G, 25 Gbit/s, 50 Gbit/s	3	PCIe 3.0	4 x SATA 3.0	N	Y	2	JTAG	5 to 105	5 to 105
LX2122RC82029B データ・シート	Rev 2	LX2162 family	アクティブ	LX2160A-RDB-B	5-year Indoor	100 @ US$265.70	1150	FBGA1150	0.65	Arm Cortex-A72	12	2000	21.6	32, 48	32, 48	6144	256	FlexSPI, L2 CACHE, SDRAM DDR4 RDIMM, SDRAM DDR4 UDIMM	2900	3	2	4	8	1	2	12	10G, 1G, 25 Gbit/s, 50 Gbit/s	3	PCIe 3.0	4 x SATA 3.0	Y	Y	2	JTAG	5 to 105	5 to 105
LX2122RE82029B データ・シート	Rev 2	LX2162 family	アクティブ	LX2160A-RDB-B	5-year Indoor	100 @ US$253.05	1150	FBGA1150	0.65	Arm Cortex-A72	12	2000	21.6	32, 48	32, 48	6144	256	FlexSPI, L2 CACHE, SDRAM DDR4 RDIMM, SDRAM DDR4 UDIMM	2900	3	2	4	8	1	2	12	10G, 1G, 25 Gbit/s, 50 Gbit/s	3	PCIe 3.0	4 x SATA 3.0	Y	Y	2	JTAG	5 to 105	5 to 105
LX2122RN82029B データ・シート	Rev 2	LX2162 family	アクティブ	LX2160A-RDB-B	5-year Indoor	100 @ US$253.05	1150	FBGA1150	0.65	Arm Cortex-A72	12	2000	21.6	32, 48	32, 48	6144	256	FlexSPI, L2 CACHE, SDRAM DDR4 RDIMM, SDRAM DDR4 UDIMM	2900	3	2	4	8	1	2	12	10G, 1G, 25 Gbit/s, 50 Gbit/s	3	PCIe 3.0	4 x SATA 3.0	N	Y	2	JTAG	5 to 105	5 to 105
LX2162RC82029B データ・シート	Rev 2	LX2162 family	アクティブ	LX2160A-RDB-B	5-year Indoor	100 @ US$287.25	1150	FBGA1150	0.65	Arm Cortex-A72	16	2000	23.9	32, 48	32, 48	8192	256	FlexSPI, L2 CACHE, SDRAM DDR4 RDIMM, SDRAM DDR4 UDIMM	2900	3	2	4	8	1	2	12	10G, 1G, 50 Gbit/s	3	PCIe 3.0	4 x SATA 3.0	Y	Y	2	JTAG	5 to 105	5 to 105
LX2162RE82029B データ・シート	Rev 2	LX2162 family	アクティブ	LX2160A-RDB-B	5-year Indoor	100 @ US$273.57	1150	FBGA1150	0.65	Arm Cortex-A72	16	2000	23.9	32, 48	32, 48	8192	256	FlexSPI, L2 CACHE, SDRAM DDR4 RDIMM, SDRAM DDR4 UDIMM	2900	3	2	4	8	1	2	12	10G, 1G, 50 Gbit/s	3	PCIe 3.0	4 x SATA 3.0	Y	Y	2	JTAG	5 to 105	5 to 105
LX2162RN82029B データ・シート	Rev 2	LX2162 family	アクティブ	LX2160A-RDB-B	5-year Indoor	100 @ US$273.57	1150	FBGA1150	0.65	Arm Cortex-A72	16	2000	23.9	32, 48	32, 48	8192	256	FlexSPI, L2 CACHE, SDRAM DDR4 RDIMM, SDRAM DDR4 UDIMM	2900	3	2	4	8	1	2	12	10G, 1G, 50 Gbit/s	3	PCIe 3.0	4 x SATA 3.0	N	Y	2	JTAG	5 to 105	5 to 105
