The MCX N23x is based on a high-performance Arm® Cortex®-M33 running up to 150 MHz, with 1MB of Flash, 352 KB ECC RAM and SmartDMA. The MCX N23x is optimized for cost, memory and system performance and offers a single core option with efficient distribution of workloads to the analog and digital peripherals.

The EdgeLock Secure Enclave on the MCX N23x is a self-contained, on-die hardware security subsystem that has its own dedicated security core, internal ROM, secure RAM and it supports state-of-the-art side-channel attack-resilient symmetric and asymmetric crypto accelerators and hashing functions for security services.

The MCX N23x devices are supported by the MCUXpresso Developer Experience to optimize, ease and help accelerate embedded system development.

データ・シート

リファレンス・マニュアル

製品詳細

ブロック図

MCX N23x MCUs

図を取得する PDF

Features

Core Platform

Arm® Cortex®-M33 @ 150 MHz

Processing Accelerators

SmartDMA (coprocessor for applications such as parallel camera interface and keypad scanning)

Memory

Up to 1 MB (2 x 512 KB Bank) on chip flash memory

Supporting Flash Swap and Read While Write

Cache Engine with 16 KB RAM
Up to 352 KB RAM, configurable as up to 288 KB with ECC (support single bit correction and two-bits detection)

Up to 4x 8 KB ECC RAM can be retained down to VBAT mode

256 KB ROM with secure bootloader

Peripherals

Analog

2x 16-bit ADC, supporting 4 parallel conversions

Each ADC can be used as two single end input ADC, or one differential input ADC

Up to 2 Msps in 16 bit mode and 3.15 Msps in 12 bit mode
Up to 61 ADC input channels (depending on the package)
One integrated temperature sensor per ADC

Two high-speed comparators with 11 input pins and 8-bit DAC as internal reference
2x CMP is functional down to deep power-down mode
High accurate VREF ±2 mV error and 15 ppm/deg C drift

Timers

Five 32-bit standard general-purpose asynchronous timers/counters, which support up to four capture inputs and four compare outputs, PWM mode and external count input. Specific timer events can be selected to generate DMA requests.
Low-Power Timer
Frequency measurement timer
Multi-Rate Timer
Windowed watchdog Timer
RTC with calendar
Wake Timer
Micro-Tick Timer (UTICK)
OS Event Timer

Communication interfaces

USB high-speed (Host/Device) with on-chip HS PHY
8x LP Flexcomms each supporting SPI, I2C, UART
2x FlexCAN with FD
2x I3C

Human-Machine Interfaces

1x FlexIO programmable as a variety of serial and parallel interfaces, including, but not limited to Display Driver and camera interface
2x Serial Audio Interface (SAI)
Digital PDM Microphone

Allows connection of up to 4 MEMS microphones with PDM output

Advanced Motor Control

2x FlexPWM each with 4 submodules, providing 12 PWM outputs (no Nanoedge module)
2x Quadrature Decoder (QDC)
1x Event Generator (AND/OR/INVERT) module support up to 8 output trigger

Security

EdgeLock® Secure Enclave, Core Profile

Cryptographic services (incl. AES-256, SHA-2, ECC NIST P-256, TRNG and key generation/derivation)
Secure key store with key usage policies (protection of platform integrity, manufacturing and application keys)
Device Unique Identity based on Physically Unclonable Function (PUF)
Device Attestation with support of Device Identifier Composition Engine (DICE)
Secure connection and TLS support
Key management over-the-air with preintegration of NXP EdgeLock 2GO

EdgeLock® Accelerator (Public Key Cryptography)
Immutable secure boot code in ROM
Dual Secure Boot Mode (asymmetric mode and fast, postquantum secure symmetric mode)
Secure firmware update support
Device lifecycle management including secure authenticated debug
High-performance on-the-fly memory encryption with additional authentication for external Flash
Protected Flash Region (PFR)
Security Monitoring:

2x Code watchdog
Intrusion and Tamper Response Controller (ITRC)
6 Active and Passive Tamper Pin Detect
Voltage, Temperature, Light and Clock Tamper Detect
Voltage glitch detect

Secure manufacturing and IP theft protection in untrusted factory
Arm TrustZone® for Cortex®-M

Packaging

VFBGA184, 9x9mm and HLQFP100, 14x14mm

MCUXpresso Developer Experience

MCUXpresso ecosystem support
- Selection of IDE choices
- Pin, clock, peripheral, security and memory config tools
- Security programming and provisioning tools
- Software development kit (SDK)
Zephyr RTOS support

‌ ‌ ‌	‌ ‌	‌ ‌	‌ ‌	‌ ‌	‌ ‌
‌ ‌ ‌	‌	‌	‌	‌	‌
‌ ‌ ‌	‌	‌	‌	‌	‌
‌ ‌ ‌	‌	‌	‌	‌	‌
‌ ‌ ‌	‌	‌	‌	‌	‌
‌ ‌ ‌	‌	‌	‌	‌	‌
‌ ‌ ‌	‌	‌	‌	‌	‌
‌ ‌ ‌	‌	‌	‌	‌	‌
‌ ‌ ‌	‌	‌	‌	‌	‌
‌ ‌ ‌	‌	‌	‌	‌	‌
‌ ‌ ‌	‌	‌	‌	‌	‌
