P5040/P5021 QorIQ® Reference Development System
The P5040DS is a high-performance computing, evaluation and development platform that supports the quad-core 64-bit P5040 device. The board, with its 2.2 GHz P5040 processor and rich I/O mix is intended for development of P5040 in networking, telecom and industrial applications, where its high performance, high-efficiency core and integrated accelerators make it very well suited as a control plane processor.
製品詳細
Features
Microcontroller
- Based on the 64-bit e5500 core, offering speeds of 1.8 to 2.2 GHz
- 20 SerDes lanes running at up to 5 GHz
- Data Path Acceleration Architecture
Memory
- DDR3 Memory Support
Connectivity
- Two x4 PCI Express slots
- Two vertical SATA connectors
- Two 10/100/1000 Ethernet ports with no add-in cards
Support
- Can support NXP®'s XAUI-RISER and SGMII-PEX-RISER option cards, optional SGMII-PEX-RISER expands 10/100/1000 port count to five
