MPC8308-RDB Reference Platform

MPC8308RDB
製造中止

画像にカーソルを合わせると拡大表示されます。

The NXP® MPC8308RDB reference platform is ideal for hardware and software development for applications including consumer printing, wireless access points, industrial control and factory automation.

The ultra-low-cost MPC8308 communications processor meets the requirements of several low-end embedded networking applications that require low power consumption, high-speed peripherals and a small-footprint package design.

製品詳細

対応製品

プロセッサ＆マイクロコントローラ

PowerQUICC II Pro (MPC83xx)

  • MPC8308: Low-Power PowerQUICC® II Pro Processor with DDR2, eSDHC, PCI Express, eTSEC, USB, IEEE® 1588

Features

Microcontroller

  • MPC8308 PowerQUICC® II Pro processor up to 333/266 MHz (CPU/DDR2)

Memory

  • 32-bit DDR2 memory controller with population option for 16-bit
    • Local bus
  • NAND flash/NOR flash memory

Connectivity

  • Ethernet
    • Four-port Gigabit Ethernet switch, supporting RGMII/MII
    • Single Gigabit Ethernet PHY (RGMII)
  • PCI Express® interconnect
    • MiniPCI Express for WLAN
  • Single high-speed USB 2.0 supporting host, device, or OTG
  • eSDHC
    • Single-port SD/MMC connector

Components

  • Two I²C
  • Dual UART

Support

  • IEEE® 1588v2 support for timing synchronization
