QorIQ® Qonverge BSC9131 RDB for Femtocell Base Station Development

BSC9131RDB アクティブ
Insider Views of Network Growth and Complexity

動画の上をクリックすると再生されます。

The QorIQ® Qonverge BSC9131 reference design board (RDB) application development system enables development of L1, L2 and L3 protocol stacks and applications ported above L3 for wireless base station applications. The reference design board can also be used to evaluate general embedded and industrial applications. The BSC9131 RDB allows for verification of BSC9131 processor device operation and provides a high level of end-to-end system performance characterization.

The highly integrated BSC9131 targets the evolving small cell base station market and combines the e500 Power Architecture CPU and SC3850 StarCore® DSP with MAPLE-B2F baseband acceleration processing elements. Together, they address the need for a high-performance, cost-effective, integrated solution that handles all required processing layers without the need for additional external processing devices.

ブロック図

BSC9131RDB BD IMG

BSC9131RDB BD IMG
図を取得する PDF

対応製品

プロセッサ＆マイクロコントローラ

Qonvergeプラットフォーム

  • BSC9131: QorIQ® Qonverge BSC9131 Single-Core Processor and Single-Core DSP

Features

Core Complex

    QorIQ® Qonverge BSC9131 Processor featuring:

  • One e500 Power Architecture core with 256 kB L2 cache
  • One StarCore® SC3850 DSP core with 512 kB L2 cache

Connectivity and Networking

  • Two Gigabit Ethernet RJ-45 jacks with RGMII interconnect
  • TDM interface via 1 RJ11 jack
  • Two RF daughter card connectors supporting 1 MAXPHY interface or 3 JESD207 interfaces

Memory System

  • 2 GB DDR3 at 800 MHz
  • 128 MB NAND Flash

Basic Peripherals and Interconnect

  • SIM card slot with 3 V and 1.8 V support (Class B and Class C)
  • USB 2.0 micro-AB socket
  • GPS Antenna: SMA or MCX female
  • RS-232 DB-9 connector

Additional Features

  • FCC certified
  • Mini-ITX enclosure
  • 12 V DC Power: 12 V DC @ 5.5 A, 100-240 V AC input
  • Operating temperature: 0 °C to 40 °C, humidity 5 % to 95 % RH

Software

もっと見る

購入オプション

BSC9131RDB-Image

クリックして展開

  • BSC9131RDB
    アクティブ

  • QorIQ Qonverge BSC9131 Reference Design Board.
