Matrix LED Controller ASL5115SHN Evaluation / Development Board.
- Cable harness for power supply and CAN bus
Contact you local sales or distributor for board availability
Matrix LED Controller ASL5115SHN Evaluation / Development Board
ASL5115EVBMST features the ASL5115SHN. The ASL5xxxyHz family is a fully-featured and flexible Matrix LED Controller (MLC). It provides a cost-effective design solution, specifically targeting advanced automotive exterior lighting applications. ASL5115SHN is controlled in direct mode, where the microcontroller updates the PWM information of each channel in a determined cycle. ASL5115SHN offers a 12-bit resolution in the PWM output, ensuring a smooth dimming performance to avoid glitches in the output light.
製品詳細
対応製品
パワーマネージメント
セーフティSBC
- UJA1163TK: Mini High-Speed CAN System Basis Chip with Standby Mode
Features
MLC Key Specifications
- 12 integrated switches in 4 floating blocks
- 1.5 A maximum current per switch
- 12-bit resolution PWM
- Automated phase shifting to avoid large peak current during switching
- Single LED open/short detection
- Direct NTC and ID resistor input
- CAN interface (FD available)
- Integrated oscillator
- QM(B) support
