MCU-Link Pro Debug Probe

MCU-LINK-PRO アクティブ

画像にカーソルを合わせると拡大表示されます。

Jointly developed by NXP and Embedded Artists, the MCU-Link Pro is a fully featured debug probe that can be used with MCUXpresso IDE and 3rd party IDEs that support CMSIS-DAP and/or J-Link protocols. MCU-Link Pro is based on NXP’s MCU-Link architecture, found in the MCU-Link low cost debug probe and on board evaluation boards, and runs the same firmware as all these implementations. In addition to SWD debug, SWO profiling and a USB to UART bridge features (VCOM) found in the base MCU-Link, the Pro model adds a J-Link LITE firmware option, energy measurement, analog signal monitor, USB to SPI and I²C bridging capability and an on-board LPC804 for peripheral emulation. MCU-Link Pro is based on the dual Arm® Cortex-M33® core LPC55S69 microcontroller, and features a high speed USB interface, providing high performance debug at low cost.

The USB bridging feature is supported by the free LIBUSBSIO host library from NXP.

MCU-Link is compatible with Windows 10 and 11, MacOS and Linux. A free utility from NXP, also included with the LinkServer package, provides an easy way to install firmware updates.
