Multi-Channel (5) PMIC for Automotive Applications: 3 LVBUCK and 2 LDO, Fit for ASIL B Safety Level

PF5103 製造開始前

画像にカーソルを合わせると拡大表示されます。

The PF5103 is a multi-channel PMIC device designed to be used for automotive safety and industrial applications. The PF5103 is configurable making it a great companion and fit for various system level power requirements.

Integrated voltage monitoring circuits ensure compliance with ISO 26262 standard and functional safety ASIL B level. The PF5103 is available as a standard non-safety device for applications that don't require the ISO 26262 compliance.

The PF5103 is suitable for the application that requires multi power supply, including infotainment, ADAS, vision and radar as a companion to another NXP PMIC a SBC like the FS8x family.

This device is suitable for S32R processors-based applications.

ブロック図

Multi-Channel (5) PMIC for Automotive Applications

PF5103 Block Diagram
図を取得する PDF

Features

Key Features

  • Three LVBUCK converters up to 3.5 A
  • Two LDO up to 200 mA and 500 mA
  • 28-pin 4.5 mm x 4.5 mm FC-QFN package

System Features

  • OTP (One-time programmable) memory for flexible device configuration
  • High-speed I²C interface (3.4 MHz)
  • PGOOD monitoring circuits
  • External clock synchronization
  • Frequency spread spectrum
  • Multi PMIC synchronization bus

Monitoring Circuits to Fit ASIL B Safety Level

  • Independent circuits to fit ASIL B safety level
  • Voltage monitoring with programmable fault protection
  • Watchdog simple window
  • I²C CRC and write protection mechanism
  • Analog built-in self-test (ABIST)

Programmability

  • Supplies, sequencing and specific functions can be programmed by one time programmable (OTP) memory
  • During development phase, customized OTP part can be programmed using the evaluation board
  • Custom OTP can be provided for production. Please contact your NXP sales channel (NXP or your distributor)
  • Custom OTP can be created using the GUI tool
